3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance
3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance
3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance
3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance
3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance
3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance
3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance
3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance
3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance
3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance
3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance
3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance
Specifications
Place of Origin :
Beijing, China
Brand Name :
TCHD
Model Number :
UV6000
Packaging Details :
Carton box
Supply Ability :
100 Piece/Pieces per Month cctv cameras
Price :
$350.00/pieces 1-9 pieces
Warranty :
1 Year
Special Features :
Low Power
Sensor :
CMOS, 1/2.8 inch high quality HD CMOS sensor
Style :
Mini camera
Function :
Wide Angle
Video Compression Format :
H.264
Data Storage Options :
Full HD
Application :
Indoor, Tele education,lecture capture,Webcasting,Videoconferencing,etc
Customized support :
Customized logo, OEM, ODM
Technology :
NetWork
Video interfaces :
3G-SDI, LAN
Effective pixels :
16: 9 2.07 megapixel
Video format :
1080P60/50/30/25/59.94/29.97;1080I60/50/59.94
DNR :
2D & 3D DNR
Network Protocol :
RTSP, RTMP, GB/T28181
Video compression format :
H.264; H.265
Control signal interface :
RS 485
Description

3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance

Introduction

3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance

TCHD TC-UV6000 series camera offers perfect functions, superior performance and rich interfaces .The features include advanced ISP processing algorithms to provide vivid images with a strong sense of depth, high resolution, and fantastic color rendition. It supports H.264/H.265 encoding which makes motion video fluent and clear even under less than ideal bandwidth conditions.

3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance

Technical Specification

Model

TC-UV6000

Camera Parameter

Lens (detachable lens)

2.8-12mm lens 5x zoom

5-60 mm lens 12x zoom

Sensor

1/2.8 inch high quality HD CMOS sensor

Effective Pixels

16: 9 2.07 megapixel

Video Format

1080P60/50/30/25/59.94/29.97;1080I60/50/59.94;

720P60/50/30/25/59.94/29.97

Auto Iris

DC driving mode

Digital Zoom

X5

Minimum Illumination

0.5Lux (F1.8, AGC ON)

DNR

2D & 3D DNR

White Balance

Auto / Manual/ One Push/ 3000K/3500K/4000K/4500K/5000K/5500K/

6000K/6500K/7000K

Focus

Manual

Aperture

Auto/Manual

Electronic Shutter

Auto/Manual

BLC

ON/OFF

WDR

OFF/ Dynamic level adjustment

Video Adjustment

Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve

SNR

>55dB

Input/Output Interface

Video Interfaces

3G-SDI,LAN

Image Code Stream

Dual stream output

Video Compression Format

H.264, H.265

Control Signal Interface

RS-485

Control Protocol

VISCA/Pelco-D/Pelco-P; Baud Rate: 115200/9600/4800/2400bps

Audio Input Interface

Double track 3.5mm linear input;

Audio Compression Format

AAC/MP3/G.7111A

5 Control Key

UP/DOWN/LEFT/RIGHT/CONFIRM keys for OSD setting

HD IP Interface

100M IP port(100BASE-TX);

Support VISCA protocol control through IP port.

Network Protocol

RTSP,RTMP,ONVIF,GB/T28181

Power Interface

HEC3800 power socket (DC12V)

Other Parameter

Supply Adapter

AC110V-AC220V to DC12V/1A , POE power supply(optional)

Input Voltage

DC12V±10%

Input Current

400mA(Max)

Consumption

4.8W (Max)

Store Temperature

-10℃~+60℃

Store Humidity

20% - 95%

Working Temperature

-10℃~+50℃

Working Humidity

20%--80%

Dimension

126.8mmX55mmX58.6mm

Weight

0.5KG

Application

Indoor

Remote Operation (IP)

Remote Upgrade, Reboot and Reset

Accessory

12V/1A Power supply, User Manual, Warranty card, brackets(optional)
Product Display

3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance

Main Features

1.Superb High-definition Image

It employs 1/2.8 inch high quality CMOS sensor. Resolution is up to 1920x1080 with frame rate up to 60fps and and 2 channel 1920x1080p with 30fps compression.

2.Low Noise and High SNR

Low Noise CMOS effectively ensure high SNR of camera video. Advanced 2D/3D noise reduction technology is also used to further reduce the noise, while ensuring image sharpness.

3.Muti-Format Video Outputs

Multiple interfaces include: 3G-SDI and LAN. The 3G-SDI is available for 100m transmission at 1080p60 format.

4.Multiple Video Compression

Support H.265/H.264+ video compression; Support compression of resolution up to 1920x1080 with frame up to 60fps.

5.Muti-Format Audio Inputs

Support 8000,16000,32000,44100,48000 sampling frequency, support AAC,MP3,G.711 Audio coding.

6.Multiple Network Protocol

Support ONVIF, RTSP, RTMP ,GB/T28181 protocols and support RTMP push mode, easy to link streaming media server (Wowza,FMS),support RTP multicast mode.

7.5 Control Key

UP/DOWN/LEFT/RIGHT/CONFIRM keys for OSD setting

8.Wide Application

Tele-education, lecture capture, Webcasting, Videoconferencing, Tele-training,Tele-medicine, Interrogation and Emergency command systems.

Applications

3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance

Related Products

3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance

Packaging & Shipping

3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance

Company Information

3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance3G SDI Video Interface IP Streaming CCTV Camera Mini For Video Surveillance
