Polished black surface OD 50mm 70mm 80mm 120mm nickel alloy bar inconel 718 round bar for aircraft engines
Polished black surface OD 50mm 70mm 80mm 120mm nickel alloy bar inconel 718 round bar for aircraft engines
Polished black surface OD 50mm 70mm 80mm 120mm nickel alloy bar inconel 718 round bar for aircraft engines
Polished black surface OD 50mm 70mm 80mm 120mm nickel alloy bar inconel 718 round bar for aircraft engines
Polished black surface OD 50mm 70mm 80mm 120mm nickel alloy bar inconel 718 round bar for aircraft engines
Polished black surface OD 50mm 70mm 80mm 120mm nickel alloy bar inconel 718 round bar for aircraft engines
Specifications
Brand Name :
Victory
Model Number :
Inconel 718
Certification :
ISO9001 ROHS
Place of Origin :
China
MOQ :
30 Kg
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
300 tons per month
Delivery Time :
20~40 Days
Packaging Details :
Spool Carton box, Coil package with polybag,then in woodencase
Name :
Polished black surface OD 50mm 70mm 80mm 120mm nickel alloy bar inconel 718 round bar for aircraft engines
Material :
Nickel Chromium Iron
Ni (Min) :
50~55%
Density :
8.24 g/cm3
Melting point :
1260-1320°C
Elongation (≥ %) :
25 %
Thermal conductivity :
15.9 W/m·K
Finishing :
Bright,Oxided, acid white
Application :
Construction, Industry Oil, piping systems
Yield strength :
550MPa
Tensile strength :
910 MPa
Hardness :
≤ 363 HB
Standard :
ASTM, ASME
size :
6~200mm
shape :
Round, Square, flat
Description

Inconel 718 alloy

INCONEL alloy 718 has excellent corrosion resistance to many media. This resistance, which is similar to that of other nickel-chromium alloys, is a function of its composition. Nickel contributes to corrosion resistance in many inorganic and organic, other than strongly oxidizing, compounds throughout wide ranges of acidity and alkalinity. It also is useful in combating chloride-ion stress-corrosion cracking.

The key mechanical properties and characteristics that make Inconel 718 a high-performance alloy

Inconel 718 is recognized as a high-performance alloy due to its exceptional mechanical properties and characteristics. Here are the key properties that contribute to its performance:

Key Mechanical Properties
High Yield Strength:

Retains high yield strength (up to 1,200 MPa or more) at both room and elevated temperatures, making it suitable for high-stress applications.
Tensile Strength:

Exhibits excellent tensile strength (up to 1,400 MPa) which is critical for components subjected to heavy loads.
Fatigue Resistance:

Outstanding resistance to fatigue failure, allowing it to withstand cyclic loading without significant degradation over time.
Ductility:

Good ductility ensures that the material can deform without fracturing, which is essential for applications that require resilience under stress.
Impact Toughness:

Maintains toughness even at low temperatures, making it suitable for applications where impact resistance is critical.
Creep Resistance:

Excellent resistance to creep deformation at elevated temperatures, which is crucial for components operating in high-temperature environments.

Parameter:

Chemical Properties of Inconel 718

Nickel (plus Cobalt) .......................................................50.00-55.00

Chromium......................................................................17.00-21.00

Iron .....................................................................................Balance

Niobium (plus Tantalum)....................................................4.75-5.50

Molybdenum .....................................................................2.80-3.30

Titanium.............................................................................0.65-1.15

Aluminum ..........................................................................0.20-0.80

Cobalt ...............................................................................1.00 max.

Carbon..............................................................................0.08 max.

Manganese .......................................................................0.35 max.

Silicon ...............................................................................0.35 max.

Phosphorus.....................................................................0.015 max.

Sulfur...............................................................................0.015 max.

Boron ..............................................................................0.006 max.

Copper..............................................................................0.30 max

Density 8.19g/cm³ 0.296 lb/in³
Melting point 1260-1336 2437°F

SPECIFICATIONS
Form
ASTM
Rod,bar and wire
B 166
Plate,sheet and strip
B 168, B 906
Seamless pipe and tube
B 167, B 829
Welded pipe
B 517, B775
Fitting
B 366
Billet and bar for reforging
B 472
Forging
B 564

Inconel series

Steel grade
Inconel 600
Inconel 601
Inconel 625
Inconel 718
Inconel 725
Inconel X-750
Corresponding brand
N06600/2.4816/1Cr15Ni75Fe8/NS312/CY40
N06601/2.4851/1Cr23Ni60Fe13AI/NS313
N06625/2.4856/0Cr20Ni65Mo10bN4/NS336
N07718/2.4668/GH4169
N07725
N07750/2.4669/GH4145
Chemical composition%
C≤
0.150
0.100
0.100
0.080
0.030
0.080
Mn≤
1.00
1.00
0.50
0.35
0.35
1.00
P≤
/
/
0.015
0.015
0.015
/
S≤
0.015
0.015
0.015
0.015
0.010
0.010
Si≤
0.50
0.50
0.50
0.35
0.20
0.50
Cr≤
14.0-17.0
21.0-25.0
20.0-23.0
17.0-21.0
19.0-22.5
14.0-17.0
Ni≤
≥72.0
58.0-63.0
≥58.0
55.0-59.0
55.0-59.0
≥70
Mo
/
/
8.0-10.0
2.8-3.3
7.0-9.5
/
Cu
≤0.50
≤1.50
/
≤0.30
/
≤0.50
N
/
/
/
/
/
Nb
/
/
3.15-4.15
4.75-5.50
2.75-4.00
0.70-1.20
other
Fe:6.0-10.0
Al:1.0-1.7
Co:≤1.0Ai:≤0.40Tr:0.40Fe:≤5.0
AI:0.20-0.80Ti:0.65-1.15B≤0.006
Tr:1.0-1.7AI≤0.35
Co:≤1.0 AI:0.4-1.0Tr:0.25-2.75Fe:5.0-9.0

Customize size as below

Shape
Size(mm)
WIre
0.5-7.5
Rod/Bar
8.0-200
Strip
(0.5-2.5)*(5-180)
Tube
custom made
Plate
custom made

contact us

email:victory@dlx-alloy.com

Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
