Specifications
Brand Name :
Jianqiao
Model Number :
JQTS2-100
Certification :
CE
Place of Origin :
China
MOQ :
1
Supply Ability :
300 sets /year
Delivery Time :
20 days
Packaging Details :
Wooden case
Model :
JQTS-50/JQTS-100/JQTS-150/JQTS-225/JQTS-408
Temperature Range :
-40°C/-55°C/-65°C~+150°C
Description

Perfection in Performance, Equipment and Design

Product Protection
• Protective mesh panels - keeps product in basket during test
• Moveable product sensor
• Hot & cold zones product temperature limiter

Extended Temperature
Range up to 250ºC
• Allows for higher
pre-temp conditioning

High Basket Loads
• Allows for heavy products to be tested
• Allows for higher throughput

Increased Productivity
• 1,000 cycles without defrost.
• Time optimized mode - higher product throughput
• Pause function - allows for uninterrupted testing
• Programmable Pre-temp function - allows for
pre-conditioning of inactive zone

Safety
• Electrical and Mechanical Transfer interlock
• Main Power disconnect
• Chamber overheat protection
• Lockable Door Latch
• Product door access protection

Energy Savings
• Green Mode - up to 40% in energy savings.
• Reduce C02 emissions

Quiet Operation
• Ideal for laboratory testing

Small Footprint
• Allows for small test lab operation


MIL-STD-883 E Method 1010.8, degree of intensity D with 4.5 kg ICs distributed over 2 shelves, measurement in specimen.

MIL-STD-883 J Method 1010.8, degree of intensity D with 12 kg ICs distributed over 3 shelves, measurement in specimen.

MIL-STD-883 F Method 1010.8, degree of intensity D with 20 kg ICs distributed over 3 shelves, measurement in specimen.

MIL-STD-883 J Method 1010.8, degree of intensity F with 25 kg ICs distributed over 3 shelves, measurement in specimen.

MIL-STD-883 F Method 1010.8, degree of intensity C with 50 kg ICs distributed over 3 shelves, measurement in specimen.


The performance data refer to +25 °C ambient temperature, 4380V V nominal voltage, without specimen, optional equipment and heat compensation.
Chambers typically use refrigerants R404A and R23. Consult factory.

Model

JQTS2-50

JQTS2-80

JQTS2-100

JQTS2-150

JQTS2-225

JQTS2-408

Inner size
W*D*H(cm)

35*32*40

50*40*40

50*50*40

65*50*46

65*70*50

85*80*60

Outer size
W*D*H(cm)

125*160*185

135*170*185

140*185*190

160*190*205

160*230*210

180*250*230

Capacityt(L)

50L

80L

100L

150L

225L

408L

Weight(kg) N.W

800

900

950

1050

1250

1450

Temp.Shock Range

A:-40℃~180℃ B:-55℃~180℃ C:-65℃~180℃

Shock type

1. High Temp.→Low Temp. 3. Normal Temp →High Temp. →Normal Temp. →Low Temp.
2. Low Temp →High Temp. 4. Normal Temp →High Temp. →Normal Temp. →Low Temp

High Temp. Chamber

+60°C~+200°C

Pre-Heating Time

(+20°C~200℃) <35 minutes

Low Temp.Chamber

(-40°C/-55°C/-65°C) ~ -10°C

Pre-cooling Time

(+20°C~-75℃ )< 60minutes

Temperature
transfer time

‘-40℃/-55°C/-65℃~+180℃ <5 second (Two Zone)

Recover time

Heat chamber Exposure 30min

Cold chamber Exposure 30 min

within 5~10min

Temp.fluctuation range

±0.5℃

Chamber material

Outer shell : standard 1.5mm electrolytic plate Baked electrostatic painting
Inner shell : standard 1.2mm thick SUS#304 stainless steel plate (matt treatment )

Insulation material


Glass fibre wool + Rigid polyurethane foam

Controller

7'LCD colorful Chinese and English touch screen (10 inch optional ),Program or fix setting ,120sets programs ,1200steps USB ,RS232 /R485 interface ,mobile APP , computer connection remote control (optional network interface )

Control system

P.I.D+S.S.R+Temp control system of microcomputer balance

Cooling type

Semi-closed two-stage compressor (water cooled)
Fully-closed two-stage compressor (air -cooled )

Refrigant

HFC-404a and HFC23 /HFC-R449A/HFC-507

Compressor

Fully closed French “Tecumseh “compressor
Semi-closed German “Bock “/"Bitzer" comporessor

Safety protection device

Fuse free switch, compressor high and low voltage protection switch,Over-temperature potector,Over -current protector , Refrigerant high -voltage protection switch, fault alarm system, electronic sound light alarm device

Spare parts

Glass viewing window , two shelves , 2*50mm cable Ports ,Casters ,

Power Supply

AC/380V,50HZ,20~50A,
