Specifications
Brand Name :
Labtone
Model Number :
RV3000
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Supply Ability :
15 Sets / Month
Delivery Time :
30-35 Working Days
Packaging Details :
International standard wooden case
Acceleration range :
0-11g(peak)
Max. Payload :
50 kg
Table Dimention :
600 x 500 mm
Frequency :
5-80 Hz
Power :
AC 220V
Warranty :
12 Month
Description

5-80 Hz Mechanical Vibration Table For Electronic Components Shake Testing

Application


Mechanical vibration test machine applies to electronic products, components, module, mechanical and electrical products, instruments and meters and other transportation vibration simulation test. It meets the standards of GB, UL, IEC vibration test and reliability test.


Specifications

Model RV3000
Table Size (L*W) 600*500mm
Frequency Range 5-80Hz
Amplitude Range 0-3mm p-p
Acceleration Range 0-11G
Max.Payload 50 kg
Control Interface (compatible interface)IBM PC Serial port Rs232 9P/USB port
Test Method Fixed frequency.sweep frequency(linear/logarithm),multi-stage random
Waveform Sine Wave
Vibration Direction Vertical
Power Supply AC 220V/50Hz
Size 765*525*690mm
Weight 250kg

Features

1, Using centrifugal excitation method, low mechanical noise.
2, Using synchronous reverse movement, excellent table evenness.
3, Stepless amplitude adjustment, meet different product test requirements.
4, Use-friendly operation control interface.
5, Fixed with shock absorption bags without special foundation.

Customer Services

Presales

  • Technical consultation: test method, laboratory planning and suggestion.
  • Equipment selection: selection scheme, FAQ.
  • Product testing scheme.

In-Sales

  • Customer communication and progress report.
  • Guidance for pre-installation preparation, equipment commissioning and test run.
  • Calibration (when Third Party’s verification is required).

After-Sales

  • Technical training: operation of equipment, daily maintenance, common fault diagnosis and troubleshooting.
  • Scheduled on-site service: Detection of problem as soon as possible in order to eliminate equipment and anthropogenic hazards. This is to ensure long term and stable equipment operation as well as delivery of latest technical information.
  • Technical support: special paid services are provided according to customer’s needs.

Product Show

Mechanical Shaker Table for Electronic Components Vibration Testing with 5-80 Hz Frequency Range and 50 kg Max PayloadMechanical Shaker Table for Electronic Components Vibration Testing with 5-80 Hz Frequency Range and 50 kg Max Payload
