Specifications
Brand Name :
LABTONE
Model Number :
EV210
Certification :
CE / ISO
Place of Origin :
China
MOQ :
1 Set
Payment Terms :
T/T, L/C
Delivery Time :
45 Working Days
Packaging Details :
Plywood Case with Vacuum Packing
Price :
Negotiable
Supply Ability :
15 Sets / Month
Frequency Range :
2 - 3000 Hz
Rated Force :
10 kN
Max. Displacement :
51 mm
Shaker Weight :
1100 kg
Shaker Dimension :
845 x 685 x 840 mm
Aggregate Capacity :
25 KW
Description

Electronics Vibration Shaker Table Systems For Lithium Battery Safety Testing System

Specifications:

Model EV103 EV203 EV106 EV206 EV210 EV220
Vibration Generator VG300/25 VG300/40 VG600/25 VG300/50 VG1000/50 VG2000/50
Frequency(Hz) 2-4000 2-2500 2-3000 2-3000 2-3000 2-2500
Max Exiting Force(kg.f) 300 300 600 600 1000 2000
Max. Displacement (mmp-p) 25 38 25 50 50 50
Max. Acceleration(g) 100 100 100 100 100 100
Max. Velocity(cm/s) 200 120 180 200 200 200
Payload(kg) 110 120 200 200 300 400
Armature Mass(kg) 3 3 6 6 10 20
Armature Diameter(mm) φ150 φ150 φ200 φ200 φ240 φ320
Cooling Method Forced Air Cooling
Vibration Generator Weight(kg) 460 460 720 920 1100 1600
Vibration Generator Dimension L*W*H(MM) 750*560*670 750*555*670 800*600*710 800*600*710 845*685*840 1200*870*1100
Power Amplifier Amp3k Amp3k Amp6k Amp6k Amp12k Amp22k
Cooling Method Forced Air Cooling
Power Amplifier Weight(kg) 250 250 320 320 350 500
Power Amplifier Dimension L*W*H(MM) 800*550*1250 800*550*1250 800*550*1250 800*550*1250 800*550*1520 800*550*1520
Utility
Requirements		 3-phase AC380V ±10% 50Hz
Aggregate Capacity(KW) 8 9 18 20 25 35

Applicable Standards: MIL-STD, DIN, ISO, ASTM, IEC, ISTA, GB, GJB, JIS, BS etc.


Applicable Industries: Automotive, Electronics, Aviation, Large Ships, Military Industry, Rail Transit, Potoelectronics, Measuring Instrument etc.


Features:

  • Dual magnetic structure;
  • Frameless armatures;
  • Pneumatic load support;
  • Rugged trunnion design with air isolation;
  • Active armature suspension system;
  • Small waveform distortion, high carrying capacity, good guidance quality;
  • Protection functions for safety interlock;
  • Good compatibity with slip table head expander, climatic test chamber, air isolation mounts, etc.

Working Principle:

Electronics Vibration Shaker Table Systems For Lithium Battery Safety Testing System

Customer Vist:

Electronics Vibration Shaker Table Systems For Lithium Battery Safety Testing System

Packaging:

Electronics Vibration Shaker Table Systems For Lithium Battery Safety Testing System
