China Factory Price Hot Press Molding Machine/Silicon Phone Case Molding Making Machine
China Factory Price Hot Press Molding Machine/Silicon Phone Case Molding Making Machine
China Factory Price Hot Press Molding Machine/Silicon Phone Case Molding Making Machine
China Factory Price Hot Press Molding Machine/Silicon Phone Case Molding Making Machine
China Factory Price Hot Press Molding Machine/Silicon Phone Case Molding Making Machine
China Factory Price Hot Press Molding Machine/Silicon Phone Case Molding Making Machine
China Factory Price Hot Press Molding Machine/Silicon Phone Case Molding Making Machine
China Factory Price Hot Press Molding Machine/Silicon Phone Case Molding Making Machine
China Factory Price Hot Press Molding Machine/Silicon Phone Case Molding Making Machine
China Factory Price Hot Press Molding Machine/Silicon Phone Case Molding Making Machine
Specifications
Place of Origin :
Guangdong, China
Model Number :
JC-HF
Brand Name :
JUCHUAN
Certification :
ISO9001:2015
Supply Ability :
1000 Set/Month
Price :
$15,000.00 - $40,000.00/sets
MOQ :
1set
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
45 days
Packaging Details :
Fixed with hard straps
Condition :
New
Style :
VERTICAL
Injection Rate (g/s) :
100
Machine Type :
Hydraulic
Injection Weight (g) :
200
Screw diameter (mm) :
40
Distance between Tie Bars :
TBD
Weight (KG) :
7500
Type :
Plate Vulcanizing Machine
Power (kW) :
15
Warranty :
1 Year
Key Selling Points :
Competitive Price
Applicable Industries :
Manufacturing Plant
Automatic :
Yes
After-sales Service Provided :
Video technical support, Online support, Engineers available to service machinery overseas
Plastic Type :
Other
Clamping Force (kN) :
200
Gross Weight(Ton) :
5~28.5
Plunger Stroke(mm) :
200~350
Port :
Guangzhou
Description

China Factory Price Hot Press Molding Machine/Silicon Phone Case Molding Making Machine

HF Series Vulcanizing Molding Machine For Two Sides Operation

Machine Feature

1.Able to assemble/install separate Ejection mechanism that suitable for bigger size molding part

2.Efficient production of rubber part for railway, mining, shipbuilding industries.

3. Multi-pillar plate vulcanizing machine.

4. Anti-collision Molding System prevent mold damage occurring from misalignment (Patented).

Model Unit 100HF 160HF 200HF 250HF 300HF 400HF 500HF 1200HF
Clamping Force Ton 100 160 200 250 300 400 500 1200

Operation table size

 mm 400*460 500*520 550*560 650*600 700*800 850*850 1000*1000 1600*2200
Plunger stroke mm 200 250 250 250 300 300 350 350

Distance of

Thermo-plate

mm 200~300 250~350 250~350 250~350 300~400 300~400 350~450 350~550
Distance of Tie bar mm 490*230 590*270 640*310 745*310 785*380 940*450 1105*475 6 posts
Die sinking type Track-Suspension-2RT-3RT-4RT

Max Operating

Pressure

 Mpa 20 20 20 20 20 20 20 20
Motor Power hp 7.5*2(5.5kw*2) 10*2(7.5kw*2) 10*2(7.5kw*2) 10*2(7.5kw*2) 10*2(7.5kw*2) 15*2(11kw*2) 15(11kw) 25(18.5kw)

Electric Heating

Power

 Kw 7.2*2 11.7*2 13.5*2 15.3*2 24*2 26.4*2 36 126
Total Power Kw 25.4 38.4 42 45.6 63 74.8 47 144.5
Gross weight Ton 5 6 7.8 11 15 17 13.5 28.5
Dimension(L*W*H) mm

2500*2080

*1950

2800*2260

*1900

2930*2350

*2050

3190*2780

*2230

3360*2970

*2250

3660*3050

*2350

1460*3600

*2380

2350*5400

*2950

China Factory Price Hot Press Molding Machine/Silicon Phone Case Molding Making MachineChina Factory Price Hot Press Molding Machine/Silicon Phone Case Molding Making MachineChina Factory Price Hot Press Molding Machine/Silicon Phone Case Molding Making Machine

Application

China Factory Price Hot Press Molding Machine/Silicon Phone Case Molding Making MachineChina Factory Price Hot Press Molding Machine/Silicon Phone Case Molding Making Machine

Product Features

China Factory Price Hot Press Molding Machine/Silicon Phone Case Molding Making MachineChina Factory Price Hot Press Molding Machine/Silicon Phone Case Molding Making Machine
