MachineU > China Products > Machinery > Plastic & Rubber Processing Machinery > Rubber Product Making Machinery
China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine
China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine
China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine
China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine
China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine
China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine
China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine
China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine
China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine
China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine
Specifications
Place of Origin :
Guangdong, China
Brand Name :
JUCHUAN
Certification :
ISO9001:2015
Packaging Details :
thin film packing
Supply Ability :
1000 Set/Month
Price :
$16,000.00 - $39,800.00/sets
Model Number :
JC-HF
MOQ :
1set
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
45 days
Condition :
New
Voltage :
380v
Dimension(L*W*H) :
2930*2350*2050mm
Weight :
7.8ton
Warranty :
1 Year
After-sales Service Provided :
Online support, Video technical support, Engineers available to service machinery overseas
Power :
42kw
Distance of Tie bar :
785*380mm
Plunger Stroke(mm) :
300
Dimension(L*W*H)mm :
3360*2970*2250
Operation table size (mm) :
700*800
Port :
Guangzhou
Description

China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine

Machine Characteristic:

1.Able to assemble/install separate Ejection mechanism that suitable for bigger size molding part

2.Efficient production of rubber part for railway, mining, shipbuilding industries

3.Multi-pillar plate vulcanizing machine.

4.Anti-collision Molding System prevents mold damage occurring from misalignment (Patented).

5.It has various demolding method: 2RT, 3RT, 4RT.

6.Accure mold positioning to ensure safety to that mold does not collide.

7.Dual power bank design to ensure the twin stations could work independently and safely.

Technical parameter:

Model

Unit

160HF

200HF

250HF

300HF

Clamping Force

Ton

160

200

250

300

Operation table size

mm

500*520

550*560

650*600

700*800

Plunger stroke

mm

250

250

250

300

Distance of

mm

250~350

250~350

250~350

300~400

Thermo-plate

Distance of Tie bar

mm

590*270

640*310

745*310

785*380

Die sinking type

Track-Suspension-2RT-3RT-4RT

Max Operating

Mpa

20

20

20

20

Pressure

Motor Power

hp

10*2(7.5kw*2)

10*2(7.5kw*2)

10*2(7.5kw*2)

10*2(7.5kw*2)

Electric Heating

Kw

11.7*2

13.5*2

15.3*2

24*2

Power

Total Power

Kw

38.4

42

45.6

63

Gross weight

Ton

6

7.8

11

15

Dimension(L*W*H)

mm

2800*2260*1900

2930*2350*2050

3190*2780*2230

3360*2970*2250

Product show

Product show:

China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine

China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machineChina Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine

Related Products

Related product:

China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine

China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine

Application Products
China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine

Our Main Products

Silicone rubber injection molding machine

Vertical hydraulic rubber injection machine

Horizontal silicone rubber injection machine

Liquid silicone injection molding machine

Vacuum compression machine

Silicone rubber hot press machine

China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine

China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine

Company Information

* Guangzhou JuChuan Machinery Co. Ltd. has been established in 1997 with a covering area of 20,000 square meters and over 20 sets of processing equipment. Our major products are including silicone rubber injection molding machine, vacuum compression molding machine, hydraulic hot press machine, injection molds, customized equipment and auxiliary equipment like robot arms.

* Our products have gained the national patents with efforts of the esteemed engineers, the advanced R&D ability, and the long-term technical cooperation with German company. We have a completed quality management system and excellent after-sale service system based on the standard GB/T19001-2016/ISO9001-2015. With the idea of "Quality is the BASIC to create value", we commit to provide the best technical support and sales services for all our customers.

* Nowadays, our products export to Germany, Russia, Ukraine, Turkey, Thailand, Vietnam, Malaysia, Indonesia, India, Cambodia, Saudi Arabia, Sudan, South Africa, Nigeria, Kenya, Morocco, Pakistan, Iran, Tunisia, Egypt, Israel, Afghanistan, Kazakhstan, Guatemala and Mexico.

China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine

China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine

Exhibition show

China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine

Our service

1. Free technology training: you can come for inspection and training for free.

2. Free Installation and debugging: Our engineers will teach you about the installation and debugging for free.

3. After-sales service: We will supply the free repairmen on this machine for one year, but will supply the maintenance lifetime. (The service is only for natural damage)

4. Online remote control for software problems, whatspp or wechat for video checking.

China Factory Sale non-standard oil seal Hydraulic Vulcanizing Hot press making machine/molding rubber injection machine
