Soft Starters with Integrated Bypass (5.5-500 kW) for Crushers and Pumps
Soft Starters with Integrated Bypass (5.5-500 kW) for Crushers and Pumps
Soft Starters with Integrated Bypass (5.5-500 kW) for Crushers and Pumps
Soft Starters with Integrated Bypass (5.5-500 kW) for Crushers and Pumps
Soft Starters with Integrated Bypass (5.5-500 kW) for Crushers and Pumps
Soft Starters with Integrated Bypass (5.5-500 kW) for Crushers and Pumps
Specifications
Brand Name :
VEIKONG
Model Number :
200kw Bypass Soft Starter
Certification :
CE
Place of Origin :
China
Payment Terms :
MoneyGram,Western Union,T/T,D/P,D/A,L/C
Supply Ability :
15000pcs per Month
Delivery Time :
3 days, depend on the order quantity
Packaging Details :
Carton and Wooden Box
Output Frequency :
50/60Hz
Output Power :
5.5KW - 500KW
Output Voltage :
0-380V
Weight :
As Per Unit
Type :
Bypass Type,Starting Motor
Color :
Dark Blue
OEM :
Support
Bypass Contactor :
Support
Highlight :
400kw Motor Soft Starter, 400kw intelligent motor starters, 500kw Bypass Soft Starter
Description

Soft Starters with Integrated Bypass (5.5-500 kW) for Crushers and Pumps


Product feature


VKS-8000 is a highly intelligent, very reliable and easy to use soft starter. The newly designed functions of VKS-8000 are used for quick setting or more personalized control.

It's a perfect solution. Its performance includes:

Large LCD screen that can display feedback information in Chinese and English languages, other languages can be customized.

Remotely installable operation panel.

Intuitive programming.

Advanced start and stop control functions.

A series of motor protection functions.


Extensive performance monitoring and event logging.


Technical Specification


Item Description
Input Power Supply Input Voltage Three-phase 380V/480V/660 AC
Frequency 50/60Hz
Adaptive Motor Squirrel-cage three-phase asynchronous motor
Starting Times It is recommended not to exceed 20 times per hour.



Control Mode

(1) Operation panel control.

(2) Operation panel + external control.

(3) External control.

(4) External control + COM control.

(5) Operation panel + external + COM control.

(6) Operation panel + COM control.

(7) COM control.

(8) No start or stop operation.


Start Mode

(1) Current-limiting to start.

(2) Voltage ramp to start.

(3) Torque control + current-limiting to start.

(4) Torque control + voltage ramp to start.

(5) Current ramp to start.

(6) Voltage current-limiting double closed-loop start.
Stop Mode

(1) Soft stop.

(2) Free stop.






Protective Function

(1) Open loop protection for external instantaneous stop terminals.

(2) Over-heat protection for soft starter.

(3) Protection for too long starting time.

(4) Input open phase protection.

(5) Output open phase protection.

(6) Unbalanced three-phase protection.

(7) starting over current protection.

(8) Running overload protection.

(9) Under voltage protection for power voltage.

(10) Overvoltage protection for power voltage.

(11) Protection for fault parameter setting.

(12) Load short circuit protection.

(13) Auto restart or incorrect wiring protection.

(14) Incorrect wiring protection of external control stop terminals.


Ambient

 Place to be used Indoor location with good ventilation free from corrosive gas and conductive dust.
Altitude

Below 1000M. It have to rise the rate power when the altitude is more than 1000M.
Temperature -20 +45 C
Humidity 90%RH without dew condensation.
Vibration <0.5G
Structure Protection Class IP20
Cooling Pattern Fans cooling.


Soft Starters with Integrated Bypass (5.5-500 kW) for Crushers and Pumps

Product Application


Soft Starters with Integrated Bypass (5.5-500 kW) for Crushers and PumpsSoft Starters with Integrated Bypass (5.5-500 kW) for Crushers and Pumps


Soft Starters with Integrated Bypass (5.5-500 kW) for Crushers and Pumps
