HT-780 Refrigeration Unit with 7300W Cooling Capacity, Parallel Flow Condenser, and -25°C To +25°C Range for Cold Transportation
HT-780 Refrigeration Unit with 7300W Cooling Capacity, Parallel Flow Condenser, and -25°C To +25°C Range for Cold Transportation
HT-780 Refrigeration Unit with 7300W Cooling Capacity, Parallel Flow Condenser, and -25°C To +25°C Range for Cold Transportation
HT-780 Refrigeration Unit with 7300W Cooling Capacity, Parallel Flow Condenser, and -25°C To +25°C Range for Cold Transportation
Specifications
Price :
negotiation
Cooling capacity :
7300 W
Supply Ability :
1000
Certification :
CE/ISO
Delivery Time :
20
Temperature range :
-25°C To +25°C
Evaporator dimensions :
1240×600×345
Payment Terms :
L/C,T/T
Brand Name :
YINHUASHENG
Condenser dimensions :
1480×500×510
Place of Origin :
CHINA
MOQ :
1PCS
Model Number :
HT-780
Packaging Details :
WOODEN CASE/CARTOON
Compressor capacity :
209 CC
Refrigerant type :
R404a
Description
HT-780 Refrigeration Unit for Cold Transportation with -25°C To +25°C Range, 7300W Cooling Capacity, and Parallel Flow Condenser
Product Overview

The HT-780 refrigeration unit is engineered for reliable temperature control in refrigerated trucks, vans, and lorries. Designed specifically for volumes up to 32m³, this system ensures optimal preservation of chilled and frozen goods during transport.

Key Advantages
  • Direct engine drive system for efficient operation
  • Specifically designed for 40m³ refrigerated transport vehicles
  • Ideal for transporting chilled & frozen foods, medical supplies, fruits, vegetables, ice cubes, and seafood
  • OEM customization services available
  • Low operational and maintenance costs
  • Easy installation process
  • Suitable for long-distance transportation requirements
Technical Features
  • Eco-friendly refrigerant R404A (R134a system also available)
  • Corrosion-resistant, high-strength FRP canning material
  • Aluminum fin parallel flow condenser - lightweight, compact design with superior heat exchange
  • Inner grooved copper tube evaporator with large airflow and enhanced coil protection
  • Robust, reliable compressor specifically engineered for R404a systems
  • Digital display control panel for minimal operation complexity
  • High and low pressure switch safety protection
  • Large cooling capacity with dependable performance
Product Images
HT-780 Refrigeration Unit with 7300W Cooling Capacity, Parallel Flow Condenser, and -25°C To +25°C Range for Cold Transportation
HT-780 Refrigeration Unit with 7300W Cooling Capacity, Parallel Flow Condenser, and -25°C To +25°C Range for Cold Transportation
HT-780 Refrigeration Unit with 7300W Cooling Capacity, Parallel Flow Condenser, and -25°C To +25°C Range for Cold Transportation
Technical Specifications
Unit Model HT-780
Applicable Temperature -25°C To +25°C
Box Volume ≤32m³
Cooling Capacity (0℃/+30℃) 7300 W
Cooling Capacity (-18℃/+30℃) 4350 W
Compressor Model GY21
Compressor Capacity 209 CC
Lubricating Oil PAG 68
Evaporator Material Inner grooved copper tube
Evaporator Fans 3 PCS
Condenser Material Parallel flow condenser
Condenser Fans 2 PCS
Refrigerant R404a
Refrigerant Charge 3.0KG
Temperature Control Electronic digital display
Safety Protection High and low pressure switch
Defrosting System Hot gas defrost automatically
Evaporator Weight 33 KG
Condenser Weight 55 KG
Evaporator Dimensions 1240×600×345
Condenser Dimensions 1480×500×510
Drive Model Non-independent engine driven
