Vehicle Refrigeration Unit with 6100W Cooling Capacity Parallel Flow Condenser and Direct Engine Drive
Vehicle Refrigeration Unit with 6100W Cooling Capacity Parallel Flow Condenser and Direct Engine Drive
Vehicle Refrigeration Unit with 6100W Cooling Capacity Parallel Flow Condenser and Direct Engine Drive
Vehicle Refrigeration Unit with 6100W Cooling Capacity Parallel Flow Condenser and Direct Engine Drive
Specifications
Cooling Capacity :
6100W (0℃), 3130W (30℃)
Compressor Displacement :
177 CC
Temperature Range :
-25°C To +25°C
MOQ :
1SET
Payment Terms :
TT/LC
Supply Ability :
1000 sets per month
Refrigerant :
R404a
Condenser Material :
Parallel flow condenser
Evaporator Material :
Inner grooved copper tube
Brand Name :
Yinhuasheng/OEM
Model Number :
HT-680
Certification :
CE
Place of Origin :
China
Description
Vehicle Refrigeration Equipment with Maximum Airflow Rate
Product Overview
This vehicle refrigeration unit features direct engine drive and is specifically designed for 27m³ refrigerated trucks. It efficiently transports chilled and frozen foods, medical supplies, fruits, vegetables, ice cubes, seafood, and other temperature-sensitive cargo.
  • Direct engine drive system
  • Powered by vehicle engine
  • OEM customization services available
  • Low operational and maintenance costs
  • Easy installation process
  • Ideal for long-distance transportation
Key Features
  • Eco-friendly R404A refrigerant (R134a system also available)
  • Corrosion-resistant, high-strength FRP canning material
  • Aluminum fin parallel flow condenser - lightweight, compact design with excellent heat exchange
  • Inner grooved copper tube evaporator with large airflow and enhanced coil protection
  • Strong, reliable compressor specifically designed for R404a systems
  • Digital display control panel for minimal operation
  • HP and LP switch safety protection
  • Large cooling capacity with reliable performance
Product Images
Vehicle Refrigeration Unit with 6100W Cooling Capacity Parallel Flow Condenser and Direct Engine Drive Vehicle Refrigeration Unit with 6100W Cooling Capacity Parallel Flow Condenser and Direct Engine Drive Vehicle Refrigeration Unit with 6100W Cooling Capacity Parallel Flow Condenser and Direct Engine Drive
Technical Specifications
Unit Model HT-680
Applicable Temperature -25℃ ~ +25℃
Box Volume ≤ 27 m³
Cooling Capacity (W) 0℃: 6100 W
30℃: 3130 W
Compressor Model: GY17
CC: 177 CC
Lubricating Oil: PAG 68
Evaporator Material: Inner grooved copper tube
Number of fans: 3
Condenser Material: Parallel flow condenser
Number of fans: 2
Refrigerant R404a
Refrigerant Charge 3.3 Kg
Box Temperature Adjustment Electronic digital display
Safety Protection High and low pressure switch
Defrosting Hot gas defrost automatically
Weight/Dimensions Evaporator: 31 Kg
Condenser: 49 Kg
Evaporator: 1240*610*285
Condenser: 1480*500*510
Drive Model Non-independent engine driven
