4G AI Mobile DVR and Dynamic Onboard Weight Sensor for Fleet Compliance

Load Monitoring · AI Video Surveillance · 4G Tracking · Compliance Alerts

Overview

This integrated solution combines the VW9014/8 AI Mobile DVR with high-precision onboard weight sensors to ensure fleet compliance and cargo security. Using capacitive sensing technology (0.2mm accuracy), the system continuously measures load weight, synchronizes data with multi-channel video, and transmits everything via 4G to a central platform. Any overload or unauthorized weight change triggers instant alerts — helping fleet operators meet regulations while protecting cargo from loading to delivery.

How It Works

The capacitive non-contact sensor mounts on the vehicle frame without structural modification, detecting suspension deflection caused by load weight. With 0.2mm precision, shock resistance, and no moving parts, it delivers reliable readings across -20°C to 80°C environments. Data is fed via RS232 to the VW9014/8 MDVR, which overlays weight information onto video footage and streams it to the cloud.

Key Features

1. Precision Load Monitoring

• Continuous static/dynamic weighing with 0.2mm accuracy, 0.2% resolution

• Detects overload, load imbalance, and unauthorized weight changes

2. AI Video Surveillance

• Up to 8-channel 1080P recording with H.265 compression

• Optional ADAS, DSM, BSD for driver safety

• Weight data overlaid as watermark on every video frame

3. 4G Remote Monitoring & GPS Tracking

• Real-time video streaming and load data via 4G (5G optional)

• Built-in GPS/BeiDou/GLONASS with geofencing

4. Smart Alerts

• Overload / load imbalance / route deviation

• Weight decrease (theft/leakage) / weight increase (unauthorized loading)

• Sensor tamper detection

5. Compliance & Fleet Management

• Audit-ready weight+video logs for regulatory inspection

• Driver behavior monitoring, remote fuel cut-off, SOS alarm

• OTA updates, HDD+SD dual storage

Specifications

Key Benefits

• Compliance — Overload prevention with audit-ready records

• Security — Theft alerts with video evidence

• Safety — Imbalance warnings prevent rollovers

• Efficiency — Real-time visibility for better dispatch

• Accountability — Objective weight+video for dispute resolution

AI-Powered. Compliance-Ready. Remotely Managed.

Contact us to keep your fleet compliant and secure.
