Specifications
Place of Origin :
China
Brand Name :
Newbase
Delivery Time :
30 days
Payment Terms :
T/T
MOQ :
10
Supply Ability :
1000EU/M
Packaging Details :
Steel Bracket
Price :
USD 1000~10000/unit
Power Type :
AC/DC
Condition :
new
Compressor Brand :
bock/Valeo/....
Operating Temperature :
-25°C to 50°C
Heating Capacity :
25kW
Dimensions :
1200mm x 600mm x 600mm
Voltage :
DC 600V
Air Flow :
3000m³/h
Fan Type :
Centrifugal
Noise Level :
≤65dB
Installation :
Roof top mounted
Cooling Capacity :
20kW
Control System :
Microprocessor
Dimension :
4160mm×1830mm×180mm
Power Consumption :
8kW
Description
IP67 Robust Electric Bus Cab Air Conditioner
Electric Bus Air Conditioner - Pure Electric Standard Heat Pump Air Conditioning System designed for optimal performance and reliability in electric bus applications.
Key Features
High-level Component Protection: IP67 rated for robust dust and water resistance, ensuring undamaged operation even when submerged
V-shaped Vibration Damping and Noise Reduction: V-shaped structure design for effective vibration damping, creating a low-noise, comfortable passenger environment
Precise Temperature Control: PWM stepless speed regulation coupled with electronic expansion valve for precise adjustments, enabling seamless temperature transitions with energy efficiency and comfort
Product Gallery
IP67 Rated Electric Bus Air Conditioner with 20kW Cooling Capacity and Roof Top Mounted Design IP67 Rated Electric Bus Air Conditioner with 20kW Cooling Capacity and Roof Top Mounted Design IP67 Rated Electric Bus Air Conditioner with 20kW Cooling Capacity and Roof Top Mounted Design

IP67 Rated Electric Bus Air Conditioner with 20kW Cooling Capacity and Roof Top Mounted DesignIP67 Rated Electric Bus Air Conditioner with 20kW Cooling Capacity and Roof Top Mounted Design

Technical Specifications
Basic Model NBEAC-21 NBEAC-24 NBEAC-30 NBEAC-34
Structural Form Roof-mounted Integrated
Applicable Bus Length (m) 6~7 7~8.5 9~10 10~12
Cooling Capacity (KW) 18 26 30 32
Heating Capacity (Heat Pump) (KW) 20 28 36 38
Evaporator Airflow Volume (M³/h) 3200 3200 4800 7200
Condenser Airflow Volume (M³/h) 4800 6000 8000 10000
Compressor Numbers Single Single/Dual Single/Dual Single/Dual
Refrigerant R407C/410A
Size (L×W×H, mm) 2610×1600×270 2500×1920×280 2750×1920×280 3000×1920×270
Unit Weight (kg) 150 230 250 275
