Electric VCB Vacuum Circuit Breaker Eberry FZN25 12KV Outdoor
Electric VCB Vacuum Circuit Breaker Eberry FZN25 12KV Outdoor
Electric VCB Vacuum Circuit Breaker Eberry FZN25 12KV Outdoor
Electric VCB Vacuum Circuit Breaker Eberry FZN25 12KV Outdoor
Specifications
Place of Origin :
Zhejiang, China
Brand Name :
Eberry
Model Number :
FZN25
Packaging Details :
plywood Carton
Supply Ability :
10000 Unit/Units per Month
Price :
$800.00 - $1,200.00/pieces
Certification :
CE,CQC,ISO9001
MOQ :
1 set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
5-10 days
Breaking Capacity :
6KA
Rated Voltage :
12KV
Rated Current :
630
Product name :
High Voltage Vacuum Circuit Breaker
Certificate :
ISO9001
Mechanical Life :
10000 Times
Rated Frequency :
50/60 Hz
Port :
Ningbo-shanghai
Description

Eberry FZN25 12KV outdoor electric vacuum load switch VCB Vacuum Circuit Breaker

Electric VCB Vacuum Circuit Breaker Eberry FZN25 12KV Outdoor

Intorduction:

FZRN25-12D vacuum load switch and combination electric appliance, suitable for three-phase AC 50Hz ring network or terminal power supply and industrial power equipment, for load control and short circuit protection, load switch split load, closed loop current,no load transformer And cable charging current. The combination can break any current up to the rated short-circuit current.
Direct-acting isolation fracture and vacuum arc linkage are adopted. With manual and electric functions.
FZRN25-12D's unique transmission structure design, the arc extinguishing chamber is only subjected to high pressure at the moment of closing and breaking, so it is small in size and light in weight.
The FZRN25-12D enables one-time operation of the isolation fracture and the interrupter of the arc chamber.
FZRN25-12D has a grounding valve interlocking with the grounding switch between the static contact and the moving contact conductive tube, which ensures safe and convenient maintenance.
NO
Item
Unit
Value
FZN25-12D/T630-20
FZRN25-12D/T125-31.5
1
Rated voltage
KV
12
2
Rated frequency
HZ
50
3
Rated current
A
630
125
4
Rated insulation level
1min power frequency withstand voltage
KV
Arc chute break 30; ground, phase 42; isolation fracture 48
Lightning impulse withstand voltage
KV
Ground, phase 75; isolation fracture 85
5
Rated dynamic current (peak)
KA
50
-
6
4s thermal stable current
KA
20
-
7
Rated active load breaking current
A
630
125
8
Rated closed-loop breaking current
A
630
125
9
Rated cable charging breaking current
A
10
10
10
Breaking the capacity of the no-load transformer
KVA
1250
1250
11
Rated short-circuit breaking current
A
-
31.5
12
Rated transfer current, rated AC current
-
2000
13
Fuse type
J
-
SDLAK-12
SFLAJ-12
14
Impactor output energy
KA
-
2-5(medium)
15
Rated short circuit closing current
KA
50
16
Grounding switch rated dynamic current
KA
50
17
Grounding switch 2s thermal stable current
KA
20
18
Auxiliary circuit rated voltage
V
AC/CD220;110
19
Mechanical life
TIMES
10000
Electric VCB Vacuum Circuit Breaker Eberry FZN25 12KV Outdoor
Electric VCB Vacuum Circuit Breaker Eberry FZN25 12KV Outdoor
Electric VCB Vacuum Circuit Breaker Eberry FZN25 12KV Outdoor
Electric VCB Vacuum Circuit Breaker Eberry FZN25 12KV Outdoor
