All In One Vertical Stackable Home Battery Storage System With 5kWh LiFePO4 Lithium Battery
All In One Vertical Stackable Home Battery Storage System With 5kWh LiFePO4 Lithium Battery
All In One Vertical Stackable Home Battery Storage System With 5kWh LiFePO4 Lithium Battery
All In One Vertical Stackable Home Battery Storage System With 5kWh LiFePO4 Lithium Battery
All In One Vertical Stackable Home Battery Storage System With 5kWh LiFePO4 Lithium Battery
All In One Vertical Stackable Home Battery Storage System With 5kWh LiFePO4 Lithium Battery
All In One Vertical Stackable Home Battery Storage System With 5kWh LiFePO4 Lithium Battery
All In One Vertical Stackable Home Battery Storage System With 5kWh LiFePO4 Lithium Battery
Specifications
Brand Name :
Vbrite
Model Number :
VB-10KW-Vertical
Place of Origin :
China
Name :
Home Battery Storage System
Battery Voltage :
40V~58.4V
Storage Capacity :
10240Wh
Weight :
149.4kg
BMS Control :
Control Battery Performance
LED Power Display :
Traffic Light Display
MOQ :
10PCS
Packaging Details :
Carton Packing
Delivery Time :
10~15Day
Payment Terms :
L/C,T/T,D/A,D/P,Western Union
Description
All-in-One Vertical Stackable Solar Storage System with 5kWh LiFePO4 Lithium Battery for Smart, Expandable Home Energy Solutions

Specification

Model
VB-10KW-Vertical
Battery Voltage
 40V~58.4V
Storage Capacity
10240Wh
Weight
149.4kg
Type of battery LFE
Capacity 102Ah
Battery Cycle Life 6000
Modular structure 1P16S*2
Capacity for assembled cell discharging by 0.2C
≥100Ah
Standard Charge Condition
Charge with 0.5C constant current and 58.4Vconstant voltage,
charge to 58.4V,continue charging till current declineto ≤0.01C
Internal Resistance
≤80mΩ Assemblage Impedance
Cycle Life
≥6000@25℃,80%EOL
Recommend Charging Temperature
0℃～50℃
Humidity
0-90%
Maximum Altitude
3000m
Parallel Capability
Up to 6 units
LED Power Display
Traffic Light Display
BMS Control
Control Battery Performance

Features:

• Support to expand the battery capacity
• Built-in BMS
• RS485 / RS232 / CAN
• Battery cycles>6000 times
• Support AC / DC priority output

Cautions

• Do NOT expose the battery to water.
• Do NOT expose the battery to re & high temperature.
• Do NOT short circuit, crush or disassemble.
• Make sure the inverter's setting matches with the battery's charge & discharge characteristic.
• Store at 50% capacity, and recharge the battery every 3 months.
• The storage area should be clean, cool, dry and ventilated.
• Disconnect the battery from the inverter and shut down the BMS when the battery is in storage status.
