Specifications
Brand Name :
Vanka
Certification :
ISO9001：2015,CE
Place of Origin :
China
MOQ :
50 Sets
Price :
$5-$10 Sets
Payment Terms :
L/C,T/T,Western Union,MoneyGram
Supply Ability :
20000 Set/Sets per Month
Delivery Time :
30 work days
Packaging Details :
570x340x165
Type :
Evacuated Tube,Solar Water Heater Parts,Flat-Plate,Pressurized,Other
Housing material :
Stainless Steel,Plastic,copper,Colored steel,Galvanized steel
Installation :
Freestanding,Wall Mounted,direct insert
Circulation type :
Direct / Open Loop (Active),Other
Connection type :
Direct-Plug,Split,Other
Capacity :
200,300,100(L),100L,150
Pressure :
Unpressurized,Medium Pressure
Application :
Water Heater,Home Use,Bathroom/Kitchen/Apartment/Hospital/School/Factory,General,Thermal Controller
Heating system :
Thermosyphon (Passive),Batch / ICS (Passive)
Material :
carbon steel,borosilicate glass3.3,T2 Red Copper,plastic,ABS
Color :
blue,green,as you require,Silver,Raw
Usage :
solar water tank and vacuum tube,Accessories for solar water heater,Government,residential,Swimming Pool
Name :
Flat Plate Solar Collector,Frost valve,Compact non-Pressured solar water heater,solar system controller,solar collector tubes
Product name :
High quality solar water heater accessories for solar water heaters,Solar Water Heater controller TK-7,Pressured Solar Water Heater Collector
Item :
Solar Water Heater Controller TK-7,Vacuum Tube Solar Collector,Hot sale Energy efficient new design solar water heater accessory,Solar Heat Pipe Vacuum Tube
Frame :
45 Stainless Steel,stainless steel SUS201-1.2mm/ Galvanized steel-1.5mm,Galvanized Steel Alloy Or Stainless Steel Or Aluminum Alloy,Alumimum Alloy
Warranty :
5 years Durable Solaris Solar Water Heater,5 Years,10 Years,10years without any human-made damage and force majeure.
Inner tank :
SUS304-2B Stainless Steel,stainless steel SUS304-0.5mm
Vacuum tube :
58mm/1800mm,QB-AL-N/AL-47-1500,Vacuum Tube 58*1800 Or 47*1500
Description
High Power 220V Pulse Igniter for Forced Exhaust Water Heaters Thermostat Control

High-energy 220V thermostatic pulse igniter designed for forced-exhaust gas water heaters. Features powerful pulse output and thermostat-compatible interface for fast, reliable ignition. Dual-pulse protection and multiple safety checks prolong service life and improve reliability. Easy to install and compatible with many forced-vent heater models.

Key Features

  • Fast Ignition: High-energy pulse output ensures instant ignition with zero delay

  • Precise Control: Compatible with thermostat interface for accurate water temperature adjustment

  • High Success Rate: Dual pulse and dual safety ignition logic for more reliable ignition

  • Enhanced Safety: Multiple protections including flameout detection, over-voltage, and short-circuit protection

  • Easy Installation: Simple setup, compatible with various forced-exhaust gas water heaters

Technical Specifications

Item Specification
Input Voltage AC 220V ±10%
Output Voltage 12–15 kV (High-Voltage Pulse)
Operating Frequency 50/60 Hz
Ignition Method Pulse Ignition (Single/Dual Pulse Optional)
Compatible Type Forced-Exhaust Gas Water Heaters (Thermostatic/Standard)
Protection Rating IPX0 (Waterproof version optional)
Operating Temperature -10℃ ~ +60℃
Service Life (Typical) ≥100,000 Ignitions (Depending on Use)
Wiring Input Wire, Ground, Thermostat Signal Wire, Ignition Output Wire
Dimensions (Typical) 60 x 41 x 29 mm (Example)
Weight (Typical) 100–120 g
Frequently Asked Questions

Q1: Which water heaters are compatible with this igniter?
A1: This module is specifically designed for forced-exhaust (fan-assisted) gas water heaters. It is compatible with most 220V-powered models that have thermostat/temperature control interfaces. For exact compatibility, please provide the wiring diagram or the heater model number.

Q2: Does installation require a technician?
A2: If you have basic electrical and gas appliance safety knowledge, you can replace the wiring according to the manual. If not, it is strongly recommended to have a professional technician perform the installation to ensure safety.

Q3: What should I do if ignition fails?
A3: First, check whether the power supply, grounding, and gas source are normal, and whether the spark electrode gap (recommended 8–12 mm) is correct. If the issue persists, replace the ignition module or contact after-sales support.

Q4: Is there a waterproof version available?
A4: Yes, some models are available with waterproof or moisture-resistant treatment. If the product will be exposed to humid environments, it is recommended to choose a waterproof version.

Q5: What is the warranty period?
A5: The standard warranty is 12 months (depending on supplier). Please note that non-original modifications or damage caused by human error are usually not covered under warranty.
