Semi Solid Vacuum Homogenizer Mixer For Pharmaceutical & Cosmetic Industries
Semi Solid Vacuum Homogenizer Mixer For Pharmaceutical & Cosmetic Industries
Specifications
Brand Name :
DINGYI
Model Number :
ZRJ-100L
Certification :
CE, PED, ISO9001
Place of Origin :
CHINA
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
50 sets per 60 days
Delivery Time :
60 days
Packaging Details :
Export Wooden Packing
Name :
Vacuum Homogenizer Mixer
Type :
Semi Solid equipment
Weight :
1950kgs
Application :
Pharmaceutical & Cosmetic Industries
Material :
SS316L and SS304
Principle :
homogenizer or high shear mixer
High shear speed :
1150-3500rpm
certificate :
CE
Description

Semi Solid Vacuum Homogenizer Mixer For Pharmaceutical & Cosmetic Industries

Vacuum Homogenizer Mixer Advantages:

-Temperature Control

Using the electricity heating bar to heat the thermal medium inside the jacket to heat the material. The heating temperature is settable and can be controlled automatically. It is also ok to input steam for heating and input cooling water to the jacket for cooling the materials down, easy to operate.

-Mixing way

Homogenizer and blade agitator can be used separately or at the same time. The micronization, emulsifying, mixing, dispersing of materials can be finished in a short time.

Vacuum Homogenizer Mixer Parameter


· Capacity:100L
· Material: material contact part SS316L, material non-contact part SS304.
· Customized service: to provide and design total solution as per customer URS


Vacuum Homogenizer Mixer main machine:


· Slow mixer 0-40rpm with PTFE scraper
· Homogenizer 0-3500rpm (rotor and stator can adjust space)
· Heating by steam or electricity
· Pressure: chamber-0.09Mpa to 0.1Mpa, jacket 0.3Mpa for steam (standard type)
· Upper cover lifting by hydraulic
· Safety limit switch for safety operation
· Upper cover connection: Liquid feed inlet with stainless steel pipe filter, solid material inlet, vacuum inlet, compressed air inlet, breaking vacuum inlet, sight glass, CIP cleaning head, discharging port, dustproof respirator.

Vacuum system:


· Water ring type vacuum pump or oil type vacuum pump
· Safety valve for protecting the Water ring type vacuum pump


Vacuum Homogenizer Mixer Prameters

Model

 Capacity Emulsifying motor slow mixer motor Machine dimension Total power(KW)

KW

 RPM KW RPM LENGTH WIDTH HEIGHT Lifting hight
ZRJ-100 100L 4 1150-3500 1.5 10-40 2900 2100 2200 3000 29
ZRJ-120 120L 4 1150-3500 1.5 10-40 2900 2100 2200 3000 29
Product tags

vacuum mixer homogenizer

,

vacuum homogenizer cream mixer

,

vacuum homogenizer mixer
