Two-Stage Rotary Vane Vacuum Pump For Industrial 0.4kw Motor Power 475*160*248mm
Two-Stage Rotary Vane Vacuum Pump For Industrial 0.4kw Motor Power 475*160*248mm
Two-Stage Rotary Vane Vacuum Pump For Industrial 0.4kw Motor Power 475*160*248mm
Two-Stage Rotary Vane Vacuum Pump For Industrial 0.4kw Motor Power 475*160*248mm
Two-Stage Rotary Vane Vacuum Pump For Industrial 0.4kw Motor Power 475*160*248mm
Two-Stage Rotary Vane Vacuum Pump For Industrial 0.4kw Motor Power 475*160*248mm
Specifications
Model NO. :
RH010C
Pumping Speed :
9.9m3/H
Ultimate Pressure :
5*10-3mbar
Inlet Diameter :
Kf25
Motor Power :
0.4kw
Noise Level :
64
Oil Volume :
1.1L
Net Weight :
24kg
Brand :
Hokaido
Transport Package :
Carton with Pallet
Specification :
475*160*248mm
Trademark :
HOKAIDO
Origin :
Dongguan China
HS Code :
8414100090
Supply Ability :
500/ Month
Description
Two-stage Rotary Vane Vacuum Pump (2RH010C)

Product Description

A typical rotary vacuum pump is comprised of a housing, a rotor and a series of radially moving vanes, which come in dry-running or lubricated versions (the latter are the most commonly used in the majority of industrial applications). The rotor is generally the only continuously moving vane vacuum pump part. There's also a working chamber inside the housing, which is divided into two separate compartments by the rotor and vanes. Many vane vacuum pumps also include an inlet valve as a safety feature.

Rotary vane vacuum pumps are available in single-stage and two-stage versions. The stages refer to the number of times that compression actually occurs. Two-stage pumps are also able to attain a lower pressure than single-stage pumps, due to the fact that gas is only admitted during the high pressure stage.

Rotary vane vacuum pumps are ideally suited for a wide range of low and medium vacuum applications such as general and chemical laboratory, analytics, freeze drying, process engineering and more. A rotary vane pump works via positive displacement, which is when volumes of air or gas are confined within a closed space and are compressed when the space is mechanically reduced.

Product Parameters

Product Model 50/60Hz 2RH010C
Pumping Speed 50Hz 9.9m³/H
60Hz 12m³/H
Ultimate Pressure mbr 5*10-3
Inlet Diameter KF25
Voltage 50Hz 220-240/380-415V
60Hz 220-280/380-440V
Motor Power kW 0.4
Current (A) 50Hz 1.75/1.15
60Hz 2.10/1.38
Rotate Speed r/min 1400/1410
Noise Level dB 64
Oil Volume L 1.1
Net Weight kg 24

Detailed Photos

Two-Stage Rotary Vane Vacuum Pump For Industrial 0.4kw Motor Power 475*160*248mmTwo-Stage Rotary Vane Vacuum Pump For Industrial 0.4kw Motor Power 475*160*248mmTwo-Stage Rotary Vane Vacuum Pump For Industrial 0.4kw Motor Power 475*160*248mm

Installation Instructions

Two-Stage Rotary Vane Vacuum Pump For Industrial 0.4kw Motor Power 475*160*248mm

Certifications

Two-Stage Rotary Vane Vacuum Pump For Industrial 0.4kw Motor Power 475*160*248mm

Company Profile

Two-Stage Rotary Vane Vacuum Pump For Industrial 0.4kw Motor Power 475*160*248mmTwo-Stage Rotary Vane Vacuum Pump For Industrial 0.4kw Motor Power 475*160*248mmTwo-Stage Rotary Vane Vacuum Pump For Industrial 0.4kw Motor Power 475*160*248mmTwo-Stage Rotary Vane Vacuum Pump For Industrial 0.4kw Motor Power 475*160*248mm
