Specifications
Place of Origin :
Guangdong, China
Brand Name :
TUCAI
Certification :
CE certification
Price :
$39,999.00/sets >=1 sets
Type :
Inkjet Printer
Print Dimension :
320*200
Applicable Industries :
Garment Shops, Building Material Shops, Home Use, Printing Shops, Advertising Company
Condition :
New
Plate Type :
Flatbed Printer
Usage :
Paper Printer, Label Printer, Card Printer, Bill Printer, Cloths Printer
Automatic Grade :
Automatic
Color & Page :
Multicolor
Voltage :
110-220V
Dimensions(L*W*H) :
290CM*500CM*137CM
Weight :
1800 KG
Warranty :
2 years
Ink Type :
UV INK
Key Selling Points :
High Productivity
Marketing Type :
Ordinary Product
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Other
After Warranty Service :
Online support
Local Service Location :
None
Showroom Location :
None
After-sales Service Provided :
Online support
Description

Ricoh G5 Printhead 3.2m Print Width Digital Printing Machine Inkjet Led UV Flatbed Printer For Glass Phone Case Acryli

Company Information

product category

Flatbed UV Printer

model

FX3220

Quantity of nozzles

2-82-8 PCS (3 PCS as standard)

Print Head

GEN5(Ricoh)

The thickness of the medium

1-100mm(customizable)

Printing size

3200*2000mm Max

Productivity:

12-60 sqm/h

Ink Set:

K/Y/C/ M/W/LC / LM / Varnish

Print accuracy:

720*600dpi/720*90dpi/720*1200dpil

Machine power:

4500W(The fan power 3000W)

Ink:

UV curable

Interface

USB 3.0

Power supply

AC 220 V ± 5%, Hz≥20A

Dimensions

Machine(L*W*H):2900*5000*1370mm

Weight (with stand)

N.W:1800KG

Electrical requirements

Temperature 20-35°C Humidity 30-70%
Product Description

New Design 3.2m Print Width 3220 UV Flatbed Printer

Ricoh FXIIIG5-3220 equipment is a high-precision large UV flatbed machine, can be equipped with 2-16 Ricoh G5 nozzle, printing speed up to 60m2/h; Achieve high precision output up to 720*1200 DPI to meet customer production needs; The maximum width of print is 3200mm*2000mm. Print mode has 4C/6C/4C+W/6C+W/4C+W+V/6C+W+V/ double 4C/ double 6C/ can print crystal 8D and embossed effect. Products commonly known as universal printer, can print a wide range of media such as: glass, acrylic, wood, ceramic tile, metal plate, PVC board, ABS, light sheet, soft film, plastic shell and other materials. Products are suitable for many fields, such as: advertising, home decoration building materials, electronic 3C, handicrafts and other industries.

1. Imported ricoh G5 steel sprinkler head

One nozzle two channels, standard with 3, WW+CM+YK

Can add sprinkler head, color sprinkler head OR white sprinkler head OR light oil sprinkler head, up to eight color printing W+C+M+Y+K+Lc+Lm+V

2, all steel structure integral gantry milling frame

3. Open mold cast aluminum beam, calibrated by marble platform

4, Japan THK high precision silent double linear guide rail

5, Japan Fuji servo motor

6. Taiwan Shangyin high precision grinding screw

7. Segmental adsorption platform

8. German Eagus drag chain

9, genuine American PP software (one machine one code)
