E-Series Combustible Gas Detector Controller Wall Mounted Multi Probe Types
E-Series Combustible Gas Detector Controller Wall Mounted Multi Probe Types
Specifications
Brand Name :
BOEN FIRE
Model Number :
E-series RJZ901
Certification :
ISO9001、CCCF
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C,T/T
Delivery Time :
15-20 days
Operating temperature :
-10℃~+40℃
Operating humidity :
≤95%RH
Indication method :
Indicator light + liquid crystal display screen for display
Alarm method :
Audible (the sound pressure level is above 85dB and below 115dB at a distance of 1 meter) and visual alarm
Contact output :
Passive contact capacity: 10A AC220V
Installation method :
Wall-mounted type
Overall dimensions :
320mm x 230mm x 88mm(12.60in×9.06in×3.46in)
Description

E-Series Wall-Mounted Combustible Gas Alarm Controller Multi-Probe Types

1. Product Overview

The RJZ901 of the E series wall-mounted combustible gas alarm controller is used to detect the content of combustible gases or toxic gases in the air. It supports the use of divided-wire detection probes, RS485 detection probes and POWBUS detection probes, and can centrally control multiple points at the same time. This system uses a microprocessor as the control unit. When the concentration of combustible gases in the environment reaches or exceeds the preset value, the controller will immediately send out audible and visual alarms, and can drive the exhaust fan or other peripheral devices to act through the relay to prevent explosion and fire accidents, thus ensuring lives.

2. Product Features

(1) Communication bus: ≥RVSP - 2×1.5mm² shielded twisted pair
(2) Power supply line: ≥RVVP - 2×1.5mm² shielded cable or RVV - 2×1.5mm² flexible copper - core sheathed wire
(3) 4 - 20mA line: ≥RVVP - 3×1.5mm² shielded cable or RVV - 3×1.5mm² flexible copper - core sheathed wire

3. Application

This system can be widely applied to places that needs fire prevention and explosion protection, such as factories, oil depots, liquefied petroleum gas stations, coal gas stations, gas stations, spray painting booths, etc., for safety monitoring and alarming.

4. Main Technical Data

Power supply Main power supply: AC220V ± 15%, 50Hz ± 1%;
Power ≤ 15W
Output supply voltage DC24V ± 25%
Model of the supporting detector RS485/Powerbus two-bus gas detectors produced by our company
Number of connected detectors 1 piece / 2 pieces / 4 pieces / 8 pieces, optionally configured
RS485/POWBUS two-bus
Explosion-proof Grade Protection level IP54
