Hydrostatic Pressure Testing Machine Offering Precise Pressure Regulation and Leak Detection Capabilities for Enhanced Control
Hydrostatic Pressure Testing Machine Offering Precise Pressure Regulation and Leak Detection Capabilities for Enhanced Control
Hydrostatic Pressure Testing Machine Offering Precise Pressure Regulation and Leak Detection Capabilities for Enhanced Control
Hydrostatic Pressure Testing Machine Offering Precise Pressure Regulation and Leak Detection Capabilities for Enhanced Control
Specifications
Safety Protection :
Over Pressure/Over Temperature
Customized support :
OEM
Accuracy :
-1%~+2%
Test Temperature Range :
15~95℃
Test Medium :
Water
Testing Range :
0-16MPA
End caps :
Φ​16-630mm
Test Mode :
Automatic
Test curve :
Pressure-time And Pressure-temperature
Certificate :
CE, ISO
Display :
LCD
Brand Name :
TH
Model Number :
XGY-16C
Certification :
ISO9001, CE
Place of Origin :
Beijing, China
MOQ :
1 set
Payment Terms :
T/T,L/C,D/A,D/P,Western Union
Supply Ability :
20 sets per month
Delivery Time :
7 -15 days
Packaging Details :
Wooden case
Product name :
Hydrostatic Pressure Testing Machine Offering Precise Pressure Regulation and Leak Detection Capabilities for Enhanced Control
Description
Hydrostatic Pressure Testing Machine
Product Overview

This Hydrostatic Pressure & Bursting Testing Machine is engineered to perform instantaneous burst tests and prolonged pressure endurance tests on plastic pipes for fluid conveyance systems. It accurately determines failure time for thermoplastic pipes under sustained pressure loads and consists of three key components: pressure control main unit, constant-temperature test chamber, and custom-matched end caps.

Featuring high measurement precision, ergonomic design, simplified mechanical structure, exceptional operational stability, and intuitive operation, this machine has become an essential testing tool for research institutions, quality inspection authorities, and pipe manufacturing enterprises.

Key Features
  • Dual control systems: microcontroller-based operation and industrial PC-based control
  • Testing pressure range: 0-200 bar (0-20 MPa)
  • Operating temperature range: 15-95℃
  • Control precision: ±1% Full Scale (temperature and pressure)
  • Integrated overpressure and overtemperature protection mechanisms
  • Certifications: CE Certification, ISO Quality Management System Certification
  • Product classification: Fluid Pressure Endurance Equipment, Hydrostatic Pressure Tester
Technical Specifications
Parameter Specification
Model XGY-16C
Diameter range Φ16-630mm
Stations 3, 5, 6, 12, 15, 18, 20, 25, 50, 100 (customizable)
Control mode Micro-control, industrial PC control
Test pressure range 0.1-16MPa
Control accuracy ±1%
Timer range 0~10000h
Power 380V 50Hz three-phase four-wire 1.5KW
Temperature range 15-95℃
Dimensions (three stations) 715*625*1700(mm) or others
Compliance Standards
ISO1167-2006, ASTMD1598-2004, ASTMD1599, ISO9080, CJ/T108, ASTMF1335
Support & Services
  • Machine installation and on-site commissioning
  • Targeted troubleshooting and technical consultation
  • Preventive maintenance programs and emergency repair services
  • Supply of genuine spare parts and testing consumables
  • Regular software patches and system enhancement upgrades
Frequently Asked Questions
Which brand is associated with the Plastic Pipe Hydrostatic Pressure Testing Machine, and where is it produced?
The Plastic Pipe Hydrostatic Pressure Testing Machine is branded TH, with professional manufacturing facilities located in Beijing, China, under strict quality oversight.
What core function does the Plastic Pipe Hydrostatic Pressure Testing Machine serve?
This machine is engineered to conduct precise evaluations of the hydrostatic pressure resistance and bursting strength of plastic pipes, verifying their structural integrity under sustained pressure conditions.
Which categories of pipes and materials are testable with this Hydrostatic Pressure Testing Machine?
It is applicable for hydrostatic performance testing of plastic pipes and composite pipes, encompassing PP-R, PP-B, PP-A, PVC, PE, PE-X, and other similar variants.
What is the measurement accuracy level of this Hydrostatic Pressure Testing Machine?
The machine boasts a full-scale reading accuracy tolerance of no more than 0.1%, ensuring highly reliable test data.
What is the maximum pressure capacity of this Hydrostatic Pressure Testing Machine?
It is capable of withstanding a maximum test pressure of 10 MPa, which converts to 100 bar or 1450 psi, meeting diverse testing demands.
