45m3 3 Axle Propane Tank Trailer 12R22.5 Tyre Heavy Duty Mechanic Suspension
45m3 3 Axle Propane Tank Trailer 12R22.5 Tyre Heavy Duty Mechanic Suspension
45m3 3 Axle Propane Tank Trailer 12R22.5 Tyre Heavy Duty Mechanic Suspension
45m3 3 Axle Propane Tank Trailer 12R22.5 Tyre Heavy Duty Mechanic Suspension
45m3 3 Axle Propane Tank Trailer 12R22.5 Tyre Heavy Duty Mechanic Suspension
45m3 3 Axle Propane Tank Trailer 12R22.5 Tyre Heavy Duty Mechanic Suspension
45m3 3 Axle Propane Tank Trailer 12R22.5 Tyre Heavy Duty Mechanic Suspension
45m3 3 Axle Propane Tank Trailer 12R22.5 Tyre Heavy Duty Mechanic Suspension
Specifications
Brand Name :
SINOHTC
Model Number :
HTC9401LGYY
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
10 UNITS PER MONTH
Delivery Time :
30 DAYS
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Trailer type :
Fuel tanker
Axle NO. :
3
Axle brand :
FUWA,YUEK,BPW
Tank volume :
45 m3
Marerial :
Aluminium alloy
Tire size :
315/80R22.5, 12.00R20
Description

45m3 3 axle Aluminium fuel Tank semi trailer, tri axle aluminum Tanker trailer, Aluminium tanker trailer


Specifications:

45000Liters 3 Axles Aluminum Alloy Fuel Tanker Trailer
Model HTC9401LGYY
Wheel Base 1310 (mm)
Tyre Specifications 12R22.5
No. Of the Tyres 12 pcs ISO Certificated
Axle 13Tonnage
No. Of the Axles 3 pcs
Landing Gear 28 ton capacity Fuwa with static capacity of 80T
Suspension Heavy duty mechanic suspension with 10 pcs leaf spring
King Pin 2' and 3.5' inter-changeable traction pin
Departure Angle 15
Front/Rear Overhang 1900 mm
Material of the Main Beam Automatic submerged arc welded
All Aluminium. Option Main beams Q345B/ST52-3, through cross beams Q235
Body material 5454 Aluminium Alloy plates, automatic submerged arc welded
Brake System Automatic air brakes
Double pipe line air brake, front two axle is 30 air chamber, rear axle is
30/30 air chamber.
Colour As the buyers' request
Accessory One tooling boxes ,Two spare tire carrier, Two fire extinguisher
Dimension 11000x2500x3800 mm
Net Weight 6Tons
Side Wall Thickness 3mm-5mm
Spare tire carrier 1 set
Electrical System 24V, 7core socket, lights according to European standards.
Tool Box 1 box of standard tools

45m3 3 Axle Propane Tank Trailer 12R22.5 Tyre Heavy Duty Mechanic Suspension

Quality Guarantee

- All spare parts are from famous brand or your Customized.
- All spare parts are testing before assembly.
- High quality automatic and manual welding.
- Quality control supervisor do inspection before delivery.
- Acceptance for third party inspection.

1, The effective volume of tank: 40 cubic meters, the car is not dangerous goods transport vehicle. Medium: oil, density: 800 kg/m3;Shape of tank size (length x width x height) (mm) : 10500 * 2490 * 2490.Tank color can change.

2, The protective material adopt carbon steel/Q235B, lateral protection bolts and welding connection;After protection bolts and welding connection, cross section size (mm) : 130 x 50, at the height of 520 mm from the ground;

3, The optional air suspension;ABS manufacturer/model: auto brake technology development /CM2XL - 4 s / 2 k (4 s / 2 m). Adopt the speed limiter tractor.
