Specifications
Brand Name :
HOWO
Model Number :
ZZ1073XXY
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
30 UNITS PER MONTH
Delivery Time :
30 Working Days
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Engine :
YUNNEI,CHAOCHAI
Engine power :
90,100,120hp
Wheelbase :
2800mm
Tyre model :
6.50
Gearbox :
Manual
Steering :
LHD,RHD
Description

SINOTRUK HOWO 4x2 light duty truck 2 - 3 tons cargo box truck

Specification for HOWO light duty truck with dry cargo van box:

(1) 4x2 light open box cargo truck 3ton

(2) 2 Axle

(3) Euro 3 emission.

(4) Horse Power 90HP

(5) Displacement: 2.54L

(6) Load capacity: 2-3ton

(7) Certification: ISO9001 CCC,SGS

Technical Parameter

Cab Driving type 4x2 LHD RHD
Model ZZ5047c
Bunk 2 seats, AC
carriage size(mm) 3650×1810×600mm
Wheel base(mm) 2800
GVW(kg) 4330
Engine Brand Xichai
Model 4DW93-84E3F
Type 4-stroke direct injection, 4-cylinder in-line with water cooling, turbo-charging and inter-cooling
displacement 2.54L
Bore*Stroke 90*110mm
Hose Power (HP) 90
Emission standard Euro 3
Max speed 90km/h
Tire 6.50R16 tyre with one spare optional
Transmission WLY525 Manual transmission, 5 forward and 1 reverse
Front axle load capacity(kg) 1*2000
Rear axle load capacity(kg) 1*3.500
Oil tank 80L
Van capacity 2-3ton
Brake system Service brake:dual circuit compressed air brake
Parking brake (emergency brake): spring energy, compressed air operating on rear wheels
Auxiliary brake:engine exhaust valve brake
Electrics Operating voltage:24V,negative grounded
Batteries:2x12 V,165 Ah
horn,headlamps,fog lights,brake lights,indicators and reverse light
Options Vertical Muffler; ABS; Automatic Break Clearance Adjusting Arm; Traveling Data

Maintenance

  1. Check Check the oil pan, injection pump, oil bath air filter,oil in the power output gearbox, if the oil level rises regularly
  2. Check the cooling water level in the tank, if the water is not enough,please add the water to the standard level. When the temperature is below+5oC, the engine if off work,please discharge the water.(when there is no antifreeze fluid)
  3. Check and tighten bolts and nuts out of the engine, excluding oil leaks, water leaks, air leaks
  4. When working in dusty places, remove dust on the air filter. And,replace the air filter when necessary
  5. Clear dirt , dust and oil on the surface of engine
  6. Listening to the voice when diesel engine is running, observing the color of exhausted air, exclude the problem and irregularities found
  7. Replace engine oil,clean oil pan and oil strainer,oil filter tank, repalce the oil in the injection pump, according detailed manual
