Rear Hydraulic Hooklift Waste Collection Trucks 3m3 - 5m3 Body Volume
Rear Hydraulic Hooklift Waste Collection Trucks 3m3 - 5m3 Body Volume
Rear Hydraulic Hooklift Waste Collection Trucks 3m3 - 5m3 Body Volume
Rear Hydraulic Hooklift Waste Collection Trucks 3m3 - 5m3 Body Volume
Rear Hydraulic Hooklift Waste Collection Trucks 3m3 - 5m3 Body Volume
Rear Hydraulic Hooklift Waste Collection Trucks 3m3 - 5m3 Body Volume
Rear Hydraulic Hooklift Waste Collection Trucks 3m3 - 5m3 Body Volume
Rear Hydraulic Hooklift Waste Collection Trucks 3m3 - 5m3 Body Volume
Specifications
Brand Name :
SINOHTC
Model Number :
CA1075GB
Certification :
ISO9001
Place of Origin :
Qingdao China
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
50 UNITS PER MONTH
Delivery Time :
30 DAYS
Packaging Details :
Bulk cargo vessel, RO-RO vessel, 40/45 HQ container
Container volume :
3,4,5 m3
Garbage truck Type :
Roll-off
Engine power :
88hp, Euro 4
Engine Displacement :
2545cc
GVW :
4495KG
Transmission type :
Manual
Description

3m3 - 5m3 rear hydraulic hooklift garbage truck hook lifting garbage truck

This 5m3 hooklift garbage truck is light duty garbage truck series.The hook lifter garbage truck we produce is equipped with imported multi-way control valve to put the garbage container on the truck and off the truck. It is operated conveniently and high efficiently. The largest advantage of hook lift garbage truck is one truck can match with several garbage container, manpower saved. Main feature of hook lift garbage truck followed:

1. One truck can work with several garbage tanks, high efficience, low transportation cost.

2. Light curb weight, large load capacity.

3. The largest dip angle is 50 degree.

4. Hight intensity steel hook, yield strength is 490Mpa, long working life.

5. Fast working time, the time of loading and unloading is 80~120 seconds.

6. Perfect safety system: loading protect valve, hydraulic and machinery lock device for garbage tank. dip lock device, hydraulic oil filter indicator.

7. Advanced heavy tank loading supporting mechanism, no matter hard ground or hag, it can finish work with with flying colors.

The hooklift garbage truck is also called hook lifting garbage truck, hook loader garbage truck, waste bin removable garbage truck, hook lift garbage truck, etc. It consists of truck chassis, hydraulic system, hook lifting system,locking device, operation system, etc.

ItemsDescriptionsSpecifications and Types
General Truck Name Hook lift truck
Drive Type 4*2
Gross Vehicle Weight(kg)4495
Curb Weight (kg) 2450
Overall Dimensions L*W*H(mm)4860×1900×2260
EngineEngine Model SD4BW654U
Engine Brand Si Da
Fuel Type Diesel
Power 65kw/88HP
Emission Standard Euro IV
Displacement(ml) 2545
Engine Type4 cylinders in line,water cooling, turbo-charged diesel engine,inter-cooling
Chassis Chassis BrandDongfeng/ T-KING/ FOTON/ FORLAND
Front/Rear Axle Load(KG) 1500/2995
Tire No.6
Tire Specification 6.50-16 Nylon tire
Wheelbase (mm) 2800
Axle No. 2
Gear Box 5 speed forward with 1 reverse, manual
Brake Oil brake
Steering WheelLeft hand drive with power-assisted
Air Conditional Suitable for tropical climate
ContainerHook lift container volume(m3)5
Hook lift container materialCarbon steel, side:3mm, bottom:4mm

Rear Hydraulic Hooklift Waste Collection Trucks 3m3 - 5m3 Body Volume
