10 Ton Cargo Truck Chassis 4*2 Double Rear Tires Euro 3 Cummins Engine 5150 Wheelbase
10 Ton Cargo Truck Chassis 4*2 Double Rear Tires Euro 3 Cummins Engine 5150 Wheelbase
10 Ton Cargo Truck Chassis 4*2 Double Rear Tires Euro 3 Cummins Engine 5150 Wheelbase
10 Ton Cargo Truck Chassis 4*2 Double Rear Tires Euro 3 Cummins Engine 5150 Wheelbase
10 Ton Cargo Truck Chassis 4*2 Double Rear Tires Euro 3 Cummins Engine 5150 Wheelbase
10 Ton Cargo Truck Chassis 4*2 Double Rear Tires Euro 3 Cummins Engine 5150 Wheelbase
Specifications
Brand Name :
Foton
Model Number :
BJ5163
Certification :
ISO/FCC/SGS
Place of Origin :
China
MOQ :
1
Price :
negotiation
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
30 per month
Delivery Time :
30-40 working days after receipt balance payments
Packaging Details :
Nude Packing
Key Words :
Shacman Truck Tractor Head
Seats :
3
Curb Weight :
8870kg
Engine :
B210 33
Emission Standard :
EURO 3
Description

10 Ton Cargo Truck Chassis 4*2 Double Rear Tires Euro3 Cummins Engine 5150 Wheelbase

Description:

With sufficient power and good quality, it is your good transportation partner. Optional air deflector, height 3910 with air deflector, height 3570 without air deflector, optional color registration and word mark. Correspondence between curb weight/maximum allowable weight of semi-trailer saddle/total weight of quasi-trailer: 8850/16020/40000,9730/15140/39140. 10 Ton Cargo Truck Chassis

Service we can provide:
10 Ton Cargo Truck Chassis,yutong bus, higer bus, kinglong bus, golden dragon bus, sunlong bus, etc. Also can provide used trucks like howo dump trucks, tractor trucks, concrete mixer trucks, tanker trucks, and other special purpose trucks, etc.Foton Tractor Truck
Except the products, we can also provide sepcial USED VEHICLES AND USED MACHIENRY export business. We warmly welcome all customers and friends who need our service, and happy to build long-term relationship with you.Foton Tractor Truck

Overall dimensions 9000x2496x2760mm Curb weight 7760kg
Van dimensions 5200x2200x500mm Loading capacity 10T
Chassis model BJ5163 Chassis brand FOTON
Overall dimensions 8455X2405X2700mm Wheel base 5150mm
Front/rear wheel track 1960/1847mm Front/rear suspension 1365/2440 mm
Approach/departure angle 16/11° Maximum speed 79km/h
Chassis Manufacturer Beijing Foton Daimler Motor Co., Ltd.
Cab Configuration ETX2200 cab(with sleeping berth),allowable 3+2 passengers, ETX interior, air conditioner, machinery seat
Color White, other color is optional
Engine Model B210 33
Emission Euro 3
Type 6 cylinders, in-line,diesel engine
Rated power 210hp, rated power speed 2500rpm
Displacement 5900ml
Max.torque 700N.m
Bore x stroke 102x120mm
Manufacturer Beijing Foton Cummins Engine Co. Ltd.
Tire Size 11R22.5
Number 6+1 nos
Fuel tank 260L aluminum fuel tank
Front axel 4.2T
Rear axle 10T
Drive form 4X2
Suspension Multi leaf springs
Rated voltage 24V, DC
Transmissions Gear box 8JS85T, 8 speed forward 1 reverse.
Steering device Power assisted steering
Steering wheel Left hand drive
Selective configuration
If there is a slight change in the chassis parameters above, please take the actual product as the standard

10 Ton Cargo Truck Chassis 4*2 Double Rear Tires Euro 3 Cummins Engine 5150 Wheelbase10 Ton Cargo Truck Chassis 4*2 Double Rear Tires Euro 3 Cummins Engine 5150 Wheelbase10 Ton Cargo Truck Chassis 4*2 Double Rear Tires Euro 3 Cummins Engine 5150 Wheelbase
