6x4 8cbm 10cbm Used Concrete Mixer Truck
6x4 8cbm 10cbm Used Concrete Mixer Truck
6x4 8cbm 10cbm Used Concrete Mixer Truck
6x4 8cbm 10cbm Used Concrete Mixer Truck
6x4 8cbm 10cbm Used Concrete Mixer Truck
6x4 8cbm 10cbm Used Concrete Mixer Truck
6x4 8cbm 10cbm Used Concrete Mixer Truck
6x4 8cbm 10cbm Used Concrete Mixer Truck
6x4 8cbm 10cbm Used Concrete Mixer Truck
6x4 8cbm 10cbm Used Concrete Mixer Truck
6x4 8cbm 10cbm Used Concrete Mixer Truck
6x4 8cbm 10cbm Used Concrete Mixer Truck
Specifications
Brand Name :
HOWO
Model Number :
ZZ1257N3841W
Certification :
CCC, ISO, CE
Place of Origin :
CHINA
MOQ :
1 unit
Price :
$14000/unit-$18000/unit
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
30units per month
Delivery Time :
10-15 working days
Packaging Details :
Nude, Waxing before delivery
Product Name :
Used Concrete Mixer Truck
Drive Type :
6x4
Engine :
WD615.69
Dum Mixing Capacity :
10 M3
Motor :
Eaton(USA brand)
Tyre :
12.00R20
Description

Used Howo 6x4 Concrete Truck 8cbm 10 Cubic Meter Concrete Mixer Truck

Used Concrete Mixer Truck Descriptions:

Concrete mixer truck or cement truck is mainly used in transporting concrete for concrete batching plants.

It is mainly made of chassis, agitator, pressure gauge, intelligent controller, transmission or drive system,

water supply device, etc. Among this, four units such as chassis, agitator, drive system, water supply device

are imported from other countries due to several technical bottlenecks. The combination of front end of mixing

drum and reduction box is installed on the front part of shelf and rear end of mixing drum is supported by two

rear wheels. Additionally, the mixing drum is a cylinder which is thin at both ends and thick in the middle.

Its inside is equipped with clockwise fan blade which will keep mixing the concrete during transportation to

prevent it from solidifying.

USED HOWO TRUCKS SPECIFICATIONS

Chassis model ZZ1257N3841W (Overall dimension: 8560x2496x3800mm)
Engine WD615.47, 371hp, Euro II, In-line, six cylinders, two valves, supercharging inter-cooling, rear supercharger Displacement is 9.726L. Diesel fuel type, Max. Torque is 1350/1300-1600Nm/rpm.
Cabin HW76, one sleeper, two seats with air-conditioner, safety belts with double locking mechanism, new face, exterior sun visor, equipped with high position metal bumper.
Clutch ∮430 diaphragm spring clutch, hydraulic control air power assisted.
Transmission HW19710, 10 F and 2 R, manual type. Max.torque: 1390N.m
Drive Axle HC16, double reduction (central reduction+hub reduction), speed ratio:standard 5.73, optional 4.8.
Front Axle HF9, 9ton, drum brake
Chassis Frame: U-profile parallel ladder frame with section of 300x80x8mm and reinforced sub-frame, all cold riveted cross member, Equipped with HW50 PTO
Front suspension: semi-elliptic leaf springs, hydraulic telescopic double-action shock absorber and stabilizer
Rear suspension: semi-elliptic leaf springs and bogie springs, spare wheel
Fuel tank: 300 L capacity, with locking fuel cap
Steering ZF8118, hydraulic steering with power assistance, LHD
Brake system Service brake: dual circuit pneumatic brake, Parking brake:energy storage spring cutoff brake.Optional ABS and automatic slack adjust.
Tyre 12.00R20 Radial plus one spare tyre (11 units)
Mixing Tank Effective tank volume is 10m3, speed of mixing barrel is 0-16r/min, mixing obliquity is 10°,capacity of water tank is 400L, Max. Dimension of hopper is 980mm
Other Specification With Italian brand Bonfiglioli reduction gears, America brand Eton oil pump and motor

6x4 8cbm 10cbm Used Concrete Mixer Truck

Flat Rack Container Bulk Ship Ro-Ro Ship

6x4 8cbm 10cbm Used Concrete Mixer Truck

6x4 8cbm 10cbm Used Concrete Mixer Truck

6x4 8cbm 10cbm Used Concrete Mixer Truck6x4 8cbm 10cbm Used Concrete Mixer Truck

After Refurbishment

6x4 8cbm 10cbm Used Concrete Mixer Truck6x4 8cbm 10cbm Used Concrete Mixer Truck
