Woven Bag 4 Colors Automatic Cutting And Sewing Machine 20-40pcs/Min
Woven Bag 4 Colors Automatic Cutting And Sewing Machine 20-40pcs/Min
Woven Bag 4 Colors Automatic Cutting And Sewing Machine 20-40pcs/Min
Woven Bag 4 Colors Automatic Cutting And Sewing Machine 20-40pcs/Min
Woven Bag 4 Colors Automatic Cutting And Sewing Machine 20-40pcs/Min
Woven Bag 4 Colors Automatic Cutting And Sewing Machine 20-40pcs/Min
Woven Bag 4 Colors Automatic Cutting And Sewing Machine 20-40pcs/Min
Woven Bag 4 Colors Automatic Cutting And Sewing Machine 20-40pcs/Min
Woven Bag 4 Colors Automatic Cutting And Sewing Machine 20-40pcs/Min
Woven Bag 4 Colors Automatic Cutting And Sewing Machine 20-40pcs/Min
Specifications
Certification :
CE ISO
Place of Origin :
China
MOQ :
1 set
Price :
negotiate
Payment Terms :
L/C, T/T
Supply Ability :
10 sets/month
Delivery Time :
15 days
Packaging Details :
Wooden case
Name :
Automatic Bag Cutting Machine
Diameter of Roller :
<=Dia.1200mm
Roller Width :
<=800mm
Cutting Speed :
<=55PCS/Min
Cutting Length :
<=1200mm
Heating Power :
2.4kw
Motor Power :
3.5kw
Condition :
Used
Description

4 Colors Automatic Cutting And Sewing Machine For Woven Bag

Features:
Auto pneumatic fabric roll loading

EPC

Printing mark tracking, bag length contrlolled by servo system

Hot cutting, auto mouth open

Cold cutting, Servo system control (Optional)

Perforation, Carry Handle Device(Optional)

PLC centralized control, Touch screen display parameter setting and record

Newlong Sewing machine, made in Japan

Inverter control speed

Auto bag counting, folding, transportation

Technical Parameters:

Model UW-800
Max.Width of cutting bag 800mm
Diameter of unwinding cloth ≤φ1200mm
Length of cutting bag 500-1300mm
Production capacity 20-40pcs/min
Length of stitch 5-14mm
Fold wigth of bag bottom 20-30mm
Max. dia. of unwinding 1200mm
Power 7KW


Application:


Woven Bag 4 Colors Automatic Cutting And Sewing Machine 20-40pcs/MinWoven Bag 4 Colors Automatic Cutting And Sewing Machine 20-40pcs/MinWoven Bag 4 Colors Automatic Cutting And Sewing Machine 20-40pcs/MinWoven Bag 4 Colors Automatic Cutting And Sewing Machine 20-40pcs/MinWoven Bag 4 Colors Automatic Cutting And Sewing Machine 20-40pcs/Min
FAQ:

1. Are you manufacturer or trading company?

We are a specialized manufacturer.

2. Is your machine automatic or manual ?
Automatic.

3. How do you control the quality?
Professional QC team comply with TQM insure you the quality. Each step is in compliance to the standards. At the same time, we will take photos or shoot video for you.

4. What about the service offered by company?
We have professional engineering team which can design and develop the mold to arrive different customer requirement.We will send technician to your country for installation and training make sure your worker can operate the machine well.We also have the sales team to offer good service from Pre-sale to After-sale.

5. What is the machine warranty?

One Year.
