Specifications
Brand Name :
JIGUO
Model Number :
ZWC-1400-2
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
30000＄-50000＄
Payment Terms :
L/C, T/T
Supply Ability :
2 set
Delivery Time :
30DAYS
Packaging Details :
standard packaging
Reference weight of cutting paper :
50-500GSM
Max.Diameter of paper :
1650mm(65〃)Max
Max.Pieces of paper :
1400mm(55〃)Max
Cutting length :
400-1600mm
Maximum cutting speed :
300cuts/min
Maximum cutting meter speed :
300m/min
Total weight :
11000kg
Description

ZWC-1400-2 Paper Sheeter Cutter Machine，Years 2021，Reference weight of cutting paper：50-500gsm

ZWC-1400-2 Paper Sheeter Cutter Machine，Years 2021，Reference weight of cutting paper：50-500gsm

1: According to the technique of the ZWC product, the specification is intended to describe the functional requirements of automatic cutting equipment,The main process flow is:Unwinding→Inserting→Traverse Cutting→Convey→Collect

2 Technical Information

Model ZWC-1400-2 ZWC-1700-2
Reference weight of cutting paper 50-500g/m2 50-500g/m2
Max.Diameter of paper 1650mm(65〃)Max 1650mm(65〃)Max
Max.Pieces of paper 1400mm(55〃)Max 1700mm(67〃)Max
Total power 25KW 28KW
Cutting length 400-1600mm 400-1600mm
Cutting accuracy +/-0.4mm +/-0.4mm
Maximum cutting speed 300cuts/min 300cuts/min
Maximum cutting meter speed 300m/min 300m/min
Atmospheric pressure 0.8MPa 0.8MPa

Power supply

 AC380V/220Vx50HZ AC380V/220Vx50HZ
Total weight 11000kg 13000kg
Dimensions 12m×3.9m×2.35m 12m×4.2m×2.35m

3.Machine Introduction

3.1 Automatic Roll Unwinding Unit

ZWC-1400-2 Paper Sheeter Cutter Machine，Years 2021，Reference weight of cutting paper：50-500gsm

Automatic Roll Unwinding Unit is Equipped with Hydraulic Shaftless Roll Stands two clamps and Braking system, which are Easy-to-use During Roll Manipulations

3.2: Prevent curling system

ZWC-1400-2 Paper Sheeter Cutter Machine，Years 2021，Reference weight of cutting paper：50-500gsm

Adjusting the roll paper due to the curl of the paper, make the paper smooth after cutting.

3.3: Correct paper offset system

ZWC-1400-2 Paper Sheeter Cutter Machine，Years 2021，Reference weight of cutting paper：50-500gsm

There are three correct paper offset modules,that meas the upper paper will align the lower paper automatically while the all four reel

working at the same time

3.4:Sub-knife system(Selective accessories)

ZWC-1400-2 Paper Sheeter Cutter Machine，Years 2021，Reference weight of cutting paper：50-500gsm

There are totally three sub-knife, knives for web slitting and web edge trimming,and is equipped with a waste paper collector to discharge the waste paper.

3.5:Knife holder and Cutting blade

ZWC-1400-2 Paper Sheeter Cutter Machine，Years 2021，Reference weight of cutting paper：50-500gsm

A total of two knives, one fixed on the base ,the other is on the holder for rolling cutting

3.6:Conveyor

ZWC-1400-2 Paper Sheeter Cutter Machine，Years 2021，Reference weight of cutting paper：50-500gsm

Taking advantage of the velocity distinction of the conveyor, makes the paper superposition transport
