Specifications
Showroom Location :
CHINA
Place of Origin :
Shanghai, China
Operating Weight :
24200KGS
Bucket capacity :
1.2
Machine Weight :
24200 KG
Hydraulic Cylinder Brand :
ORIGINAL
Hydraulic Pump Brand :
ORIGINAL
Hydraulic Valve Brand :
ORIGINAL
Engine Brand :
6BG1-XABEC-03-C2
Power :
128.5
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Core Components :
Pressure vessel, Motor, Other, Bearing, Gear, Pump, Gearbox, Engine, PLC
Year :
2022
Working hours :
900
Used sany sy235C excavators :
used sany sy235C
track shoes sany sy235C excavators :
sany sy235C
MOQ :
3000 sets
Price :
$14,000.00 - $17,000.00/sets
Description
COMPANY

Buy Used Sany SY235C Excavator 25 Ton Digger Machine for Road Construction

Buy Used Sany SY235C Excavator 25 Ton Digger Machine for Road ConstructionBuy Used Sany SY235C Excavator 25 Ton Digger Machine for Road ConstructionBuy Used Sany SY235C Excavator 25 Ton Digger Machine for Road ConstructionBuy Used Sany SY235C Excavator 25 Ton Digger Machine for Road ConstructionBuy Used Sany SY235C Excavator 25 Ton Digger Machine for Road ConstructionBuy Used Sany SY235C Excavator 25 Ton Digger Machine for Road ConstructionBuy Used Sany SY235C Excavator 25 Ton Digger Machine for Road Construction

Name:ShangHai Long shou Machinery Co,Ltd
Address: No 1688 South Lian Hua Road, MinHang district.ShangHai, P. R. China
Contact :Tony
Whats app/ Mobile phone:+8613564042317
We chat number:13564042317

Technical parameters of Sany Heavy Industry SY235C-9 excavator

Model SY235C-9

Overall size (mm) A Total length (during transportation) 9920

B total width (transportation/operation) 2980

C total height (transportation) 3550

D Upper width 2710

E total height (top of cab) 2990

F standard track shoe width 600

G gauge (transportation/operation) 2380

H minimum ground clearance 440

Tail turning radius 2890

J Track grounding length 3640

K track length 4445

L Track height 965

Scope of work (mm) a Maximum excavation height of 9640

B Maximum unloading height 6725

Maximum excavation depth of 6785

Maximum vertical arm excavation depth of 5845

Maximum excavation distance of 10150

F Minimum turning radius 3800

The maximum height at the minimum turning radius of g is 7940

Performance parameters Total weight kg 24200

Standard bucket capacity m3 1.2

Rated power kW/rpm 128.5/2100

Walking speed (high/low) km/h 5.5/3.5

Rotating speed rpm 11

Climbing ability 70%/35 °

Grounding specific pressure kPa 47.6

Engine model 6BG1-XABEC-03-C2

Bucket excavation force (KN) 175

Dipper arm excavation force (KN) 122

Optional bucket (m3) 1.1~1.2

Optional shoe bandwidth (mm) 800/700

Buy Used Sany SY235C Excavator 25 Ton Digger Machine for Road Construction
