Specifications
Showroom Location :
CHINA
Place of Origin :
Sweden
Operating Weight :
50,500
Bucket capacity :
3
Machine Weight :
50500 KG
Hydraulic Cylinder Brand :
ORIGINAL
Hydraulic Pump Brand :
ORIGINAL
Hydraulic Valve Brand :
HYDAC, ORIGINAL
Engine Brand :
VOLVO_D13-T4(A)
Power :
245KW
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Core Components :
Pressure vessel, Motor, Other, Bearing, Gear, Pump, Gearbox, Engine, PLC
Year :
2020
Working hours :
1200
Used VolvoEC480D Crawler Excavator :
second hand VolvoEC480D Crawler Excavator
sweden volvo EC480D excavators :
track shoes volvo EC480D
Port :
SHANG HAI PORT;LIAN YUN GANG PORT;TIAN JIN PORT
Price :
$60,000.00/sets >=1 sets
Description
About us

48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes

48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes

package and shipping

load method

advantage and weekness :best ,keep machine complete and well .u can use when received it ,only waste freight

48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes

Method 2 (take boom and bucket out ,put boom on top of machine or other pieces ,same CBM )

48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes

Method 3 use 40FR Frame

48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes

48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes

Method 4 use 40HQ container ,cheapest but destroy machine

48 Tons Volvo EC480D Excavator in Sweden with VOLVO D13-T4 A Engine and Track Shoes

Volvo EC480D Excavator Parameter Configuration

specifications

Power Traditional Power

Manufacturer joint venture/import

Bucket Backhoe

Tonnage (ton) 48

Working weight of the whole machine (kg) 47900-50500

Bucket capacity (m ³) 1.77-3.80

Boom length (mm) 7

Stick length (mm) 4.8

Origin Korea

performance

Rotation speed (rpm) 8.8

Walking speed (km/h) 3.1-5.2

Climbing ability (%) 35

Ground specific voltage (Kpa) 73.7 (700mm)

Bucket excavation force (kN) 285/310.6

Dipper arm excavation force (kN) 251

dynamic system

Engine model Volvo VOLVO-D13-T4 (A)

Rated power (kW/rpm) 245

Displacement (L) 12.8

Number of cylinders (6)

Cylinder diameter x stroke (mm) 131 * 158

Cooling method: water cooling

The work format can meet the emission requirements of Stage IIIB in Europe

hydraulic system

Main pump type: piston type

Traveling hydraulic motor type: piston type

Rotary hydraulic motor type: piston type

Maximum flow rate of main pump (l/min) 2 * 358

Pilot oil circuit (MPa) 3.9

Working hydraulic oil circuit (Mpa) 32.4/35.3

Hydraulic circuit for walking (Mpa) 32.4

Rotary hydraulic circuit (Mpa) 25.8

Boom oil cylinder - number x cylinder diameter x stroke (mm) 2 * 165 * 1590

Stick oil cylinder - number x cylinder diameter x stroke (mm) 1 * 190 * 1850

Bucket oil cylinder - number x cylinder diameter x stroke (mm) 1 * 165 * 1330

Oil capacity

Fuel tank (L) 685

Hydraulic oil tank (L) 270

Hydraulic system (L) 525

Engine oil change quantity (L) 42

Cooling liquid (L) 60

Main body size

Total length of transportation (mm) 12140

Total transportation width (mm) 3367

Total transportation height (mm) 3790

Full height of cab (mm) 3090

Track grounding length (mm) 4370

Total length of track (mm) 5370

Track shoe width (mm) 700

Total width of track (mm) 3590 (in extended state)

Track gauge (mm) 2890 (in extended state)

Minimum ground clearance (mm) 746

Ground clearance of counterweight (mm) 1385

Rear end turning radius (mm) 3800

Scope of work

Maximum excavation radius (mm) 12040

Maximum excavation radius of the parking surface (mm) 11810

Maximum excavation depth (mm) 7720

Maximum excavation height (mm) 11010

Maximum unloading height (mm) 7640

Maximum vertical excavation depth (mm) 7110

Maximum effective excavation depth (mm) 7570

Arm rotation angle (left/right °) 183
