Specifications
Brand Name :
Ruckus
Model Number :
ICX 7150-24P-4X1G
MOQ :
1
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Brand :
Ruckus
Model :
ICX 7150-24P-4X1G
Product name :
Ruckus ICX 7150 switch
1GbE SFP Ports :
4
PoE + por :
24 10/100/1000Mbps
PoE power :
370W
Description

Wlan Access Point Ruckus ICX 7150-24P-4X1G 7150 Series 24 10/100/1000Mbps PoE + port Switch

Ruckus ICX 7150 switches, 24 10/100/1000Mbps PoE + port, and 2 part 1 g RJ45 port, four part 1 g SFP mouth (by license upgrade into 10 g SFP +) provide PoE power of 370 w, based on three layer function (support static routing and RIP)

Wlan Access Point Ruckus ICX 7150-24P-4X1G 7150 Series 24 10/100/1000Mbps PoE + port SwitchWlan Access Point Ruckus ICX 7150-24P-4X1G 7150 Series 24 10/100/1000Mbps PoE + port SwitchWlan Access Point Ruckus ICX 7150-24P-4X1G 7150 Series 24 10/100/1000Mbps PoE + port Switch

Switching capacity
(data rate, full duplex)
132 Gbps
Forwarding capacity
(data rate, full duplex)
98 Mpps
10/100/1000 Mbps RJ45 downlinks
24
100/1000 Mbps/2.5 Gbps RJ45 downlinks
(full duplex only)
-
10/100/1000 Mbps RJ45 uplinks
(full duplex only, no PoE)
2
1/10 Gbps SFP/SFP+ uplinks
4
PoE/PoE+ ports
24
PoH / PoE / PoE+ ports
-
Dual hot-swap power supplies
-
Maximum PoE Class 3 ports
(15.4 W per port)
24
Maximum PoE+ Class 4 ports
(30 W per port)
12
Base IPv4/v6 Layer 3 routing1
(static routing, RIP)
yes
Advanced IPv4/v6 Layer 3 routing1
(OSPF, VRRP, PIM, PBR features)
With license
Aggregated stacking bandwidth1
(data rate, full duplex)
480 Gbps
Stacking density1
(maximum switches in a stack)
12
Stacking ports1
(maximum ports2 usable for stacking)
Up to 4×10 GbE SFP+
Maximum stacking distance1
(distance between stacked switches)
10 km
Power inlet (AC)
C14
Input voltage/frequency
AC: 100 to 240 VAC @ 50 to 60 Hz
Power supply rated maximum (AC)
525 W
PoE power budget (AC)
370 W
Airflow
Side-to-back
Net Weight (Kg)
4.93
Connector options
* 10/100/1000 Mbps RJ-45
* 1 Gbps SFP ports
* 1/10 Gbps SFP+ ports
* Out-of-band Ethernet management: 10/100/1000 Mbps RJ-45
* Console management: RJ45 serial port and USB Type-C port with serial communication device class support
* File transfer: USB port, standard-A plug

Wlan Access Point Ruckus ICX 7150-24P-4X1G 7150 Series 24 10/100/1000Mbps PoE + port SwitchWlan Access Point Ruckus ICX 7150-24P-4X1G 7150 Series 24 10/100/1000Mbps PoE + port SwitchWlan Access Point Ruckus ICX 7150-24P-4X1G 7150 Series 24 10/100/1000Mbps PoE + port SwitchWlan Access Point Ruckus ICX 7150-24P-4X1G 7150 Series 24 10/100/1000Mbps PoE + port SwitchWlan Access Point Ruckus ICX 7150-24P-4X1G 7150 Series 24 10/100/1000Mbps PoE + port SwitchWlan Access Point Ruckus ICX 7150-24P-4X1G 7150 Series 24 10/100/1000Mbps PoE + port SwitchWlan Access Point Ruckus ICX 7150-24P-4X1G 7150 Series 24 10/100/1000Mbps PoE + port SwitchWlan Access Point Ruckus ICX 7150-24P-4X1G 7150 Series 24 10/100/1000Mbps PoE + port Switch
