SAC3500 Sany Second Hand Truck Cranes 350 Ton Mobile Crane 112m
SAC3500 Sany Second Hand Truck Cranes 350 Ton Mobile Crane 112m
SAC3500 Sany Second Hand Truck Cranes 350 Ton Mobile Crane 112m
SAC3500 Sany Second Hand Truck Cranes 350 Ton Mobile Crane 112m
Specifications
Brand Name :
Sany
Model Number :
SAC3500
Certification :
CE,ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Delivery Time :
5-7 Days
Packaging Details :
Bulk
Condition: :
Used
Maximum Lifting Height: :
15.2 - 112m
Maximum Lifting Weight: :
350ton
Axle Number: :
6
Jib: :
2 Section
 production date: :
2014
Description

Used Truck Crane Sany SAC3500 Second Hand Truck Mobile Crane

Production Details:

Model NO.

SAC3500

 Boom Type Telescopic

Max. Rated Lifting Capacity

 350000 kg Max. Lifting Height of Jib 70m

Max Gradeability

 49% Working Diameter 24m

Transport Package

 Complies with Min. export packaging requirements Specification

18035×3000×4000mm

Driving mileage

 820000Km Working hours 8600h

Trademark

 Sany Place of Origin China

HS Code

 Supply Capacity 10 Units Per Month

  • Sany SAC3500 engine, transmission, tires and other main parts are all well-known brands, with strong power, which can meet the driving needs of various road conditions;
  • Innovative 6-axle chassis design, one-, three-, five- and six-axle drive, full-axle steering, easy manipulation, flexible steering, and better maneuverability;
  • The driving dual-circuit braking system is adopted for safer braking; at the same time, multiple braking modes make the braking performance more reliable;
  • Fully optimized 6-section elliptical main boom makes the boom more uniform, lighter in weight and higher in safety;
  • Equipped with a Y-type super-lifting device, the lifting performance of the long boom section is more than doubled, and it can be installed without an auxiliary crane;
  • Equipped with a variety of combined variable balance weights, it can meet the needs of different working conditions and maximize the performance of structural parts.

Product Parameters:

Dimensions

Overall length: 18035mm

Overall width: 3000mm

Overall height: 4000mm
Dynamic parameters

Rated power of the engine on operating cab: 205/2200kw/(r/min)

Rated torque of the engine on operating cab: 1100/1400N.m/(r/min)

Rated power of the engine on driving cab: 440/1800kw/(r/min)

Rated torque of the engine on driving cab: 2800/1300N.m/(r/min)
Traveling parameters

Max. traveling speed: 80Km/h

Min. turning diameter: ≤ 24m

Max. grade: 49%

Braking distance (vehicle speed is 30km/h): ≤ 10m
Performance parameters

Max. lifting moment: basic arm 11520kN.m

Boom length: main boom 15.2～70m

Boom length: fixed jib 6～42m

Boom length: luffing jib 12～78m
Working speed

Main hoisting mechanism single rope hoisting speed (no-load fourth floor): 130m/min

Boom full extension/retraction time: ≥533s

Max. rotation speed: ≤1.2r/min
