QAY220 Sany Mobile Crane Sany Used All Terrain Crane 220 Ton
QAY220 Sany Mobile Crane Sany Used All Terrain Crane 220 Ton
QAY220 Sany Mobile Crane Sany Used All Terrain Crane 220 Ton
QAY220 Sany Mobile Crane Sany Used All Terrain Crane 220 Ton
QAY220 Sany Mobile Crane Sany Used All Terrain Crane 220 Ton
QAY220 Sany Mobile Crane Sany Used All Terrain Crane 220 Ton
Specifications
Brand Name :
Sany
Model Number :
QAY220
Certification :
CE , ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Delivery Time :
5-7 Days
Packaging Details :
Bulk
Condition: :
Used
Maximum Lifting Height: :
13.8 - 81m
Maximum Lifting Weight: :
220 ton
Axle Number: :
5
Jib: :
2 Section
 production date: :
2012
Description

Sany Used All-Terrain Truck Crane Sany QAY220 Ton Second Hand Crane

Production Details:

Model NO.

QAY220

 Boom Type Telescopic

Max. Rated Lifting Capacity

 220000 kg Max. Lifting Height of Jib 61.5m

Max Gradeability

 48% Working Diameter 24m

Transport Package

 Compliant with export packaging requirements Specification

16130×3000×4000mm

Driving Mileage

720000m

Working hours

8000h

Trademark

 Sany Place of Origin China

HS Code

 Supply Capacity 1 Units Per Month

  • QAY220 all-terrain crane is a high-performance and high-reliability crane designed and developed by our company in order to meet the market demand, using the technical crystallization of designing and manufacturing mobile cranes for many years and combining with international advanced technology.
  • This product is a high-tech product with a high concentration of electromechanical hydraulic systems.
  • It will be active in various fields of my country's economic construction with its excellent handling performance, excellent fretting performance, huge lifting capacity and extraordinary lifting height.
  • This product is suitable for lifting operations and installation projects in chemical, mining, oil fields, ports, construction sites and other places. This product is not suitable for areas with strong electromagnetic waves.
  • This product is an all-terrain crane with full swing, telescopic boom type, electro-hydraulic proportional control. It adopts the company's self-made six-axle dedicated all-ground chassis, with wide field of vision, luxurious and comfortable decoration, four-axle drive and five-axle steering.
  • The latest electro-hydraulic proportional reversing valve with load feedback and multi-piston variable pump is adopted, and the variable system combined with open type and closed type is adopted, so that the working ability of each actuator can be fully exerted.
  • The combined action of lifting, luffing, slewing, and telescopic mechanisms greatly improves the working efficiency of the crane. It has the characteristics of light and flexible operation, stable and reliable work, stepless speed regulation and so on.
  • In the hydraulic system, there are safety devices such as relief valve, balance valve, hydraulic lock, brake valve, etc., to prevent the overload of the oil circuit and avoid accidents caused by the rupture of the oil pipe.
  • Equipped with a variety of safety devices such as torque limiters and a complete lighting system, it can ensure safe and reliable operation and facilitate night work.

Product Parameters:

When Traveling:

Category Item Unit Value
Dimensions Overall length of the whole machine mm 16130
Overall width of the whole machine mm 3000
Overall height of the whole machine mm ≤4000
Wheelbase 1st and 2nd mm 2750
2nd and 3rd mm 1650
3rd and 4th mm 2000
4th and 5th mm 1650
5th and 6th mm 1650
Tire distance mm 2590
Weight parameters Deadweight in traveling condition kg 71000
Axle load 1st and 2nd kg 11750
3rd and 4th kg 11850
5th and 6th kg 11900
Dynamic parameters

Operating cab engine

 Engine model TAD720VE
Rated power kw/(r/min) 162/2100
Rated torque N.m/(r/min) 854/1400
Rated speed r/min 2100
Driving cab engine Rated power kw/(r/min) 390/1800
Rated torque N.m/(r/min) 2400/1200
Rated speed r/min 2000

Traveling parameters

 Traveling speed Top speed km/h 71
Min. stable driving speed km/h 2.1
Min. turning diameter m ≤24
Min. ground clearance mm 278
Approach angle ° 25
Departure angle ° 18
Braking distance (vehicle speed is 30km/h) m ≤10
Max. gradeability % 48
Fuel consumption per 100 km l 80

When Operating:

Category Item Unit Value

Main performance

 Max. rated lifting capactity t 200
Min. rated working range m 3
Turntable tail turning half warp (balance weight) mm 5070

Max. lifting moment

 Basic boom kN.m 6774
Longest main boom kN.m 2752

Outrigger distance

 Portrait m 9.625
Horizontal m 8.7(6.5)

Lifting height

 Basic boom m 14.5
Longest main boom m 61.5
The longest main boom + jib (11.55m) 73.8
The longest main boom + jib (20m) m 82.1
Boom length Basic arm m 13.8
Longest main boom m 61
The longest main boom + jib (11.55m) m 72.55
The longest main boom + jib (20m) m 81
Jib mounting angle ° 0, 15,30
Working speeds Boom luffing time Raise the boom s 60
Boom extension time Full extension s 450
Full shrink s 450
Max. rotation speed r/min 1.9
Outrigger extension time Horizontal outriggers Simultaneously stretch s 50
Shrink at the same time s 40

Vertical outrigger

 Simultaneously stretch s 50
Shrink at the same time s 45

Lifting speed

(single rope, fourth layer)

 Main hoisting mechanism Empty m/min 120
Auxiliary hoisting mechanism Empty m/min 110
External radiation dB(A) ≤118
Driver's place dB(A) ≤90

QAY220 Sany Mobile Crane Sany Used All Terrain Crane 220 TonQAY220 Sany Mobile Crane Sany Used All Terrain Crane 220 TonQAY220 Sany Mobile Crane Sany Used All Terrain Crane 220 Ton
