Used Zoomlion Crane 80 Ton Zoomlion QY80V Second Hand Truck Mobile Crane
Used Zoomlion Crane 80 Ton Zoomlion QY80V Second Hand Truck Mobile Crane
Used Zoomlion Crane 80 Ton Zoomlion QY80V Second Hand Truck Mobile Crane
Used Zoomlion Crane 80 Ton Zoomlion QY80V Second Hand Truck Mobile Crane
Specifications
Brand Name :
Zoomlion
Model Number :
QY80V
Certification :
CE, ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Delivery Time :
5-7 Days
Packaging Details :
Bulk
Condition: :
Used
Maximum Lifting Height: :
12.5—75m
Maximum Lifting Weight: :
80ton
Axle Number: :
4
Jib: :
2 Section
 production date: :
2016
Description

Used Zoomlion Truck Crane Zoomlion QY80V Second Hand Truck Mobile Crane

Production Details:

Model No.

 QY80V Boom Type Telescopic

Max. Rated Lifting Capacity

 80000 kg Max. Lifting Height of Jib 48.8m

Max Gradeability

 40% Working Diameter 24m

Transport Package

 Complies with Min. export packaging requirements Specification 15000×2850×3850

Driving Mileage

 70000Km Working hours 5000h

Trademark

 Zoomlion Place of Origin China

HS Code

 Supply Capacity 10 Units/ Month

The machine is equipped with 5 U-shaped main booms with a maximum length of 48m, a maximum lifting height of 66m, a maximum lifting capacity of 13.5t when the boom is fully extended, and has strong lifting performance. It adopts a special chassis for 4-axle heavy-duty truck cranes, with a bearing capacity of not less than 50t and a grade of not less than 40%. The rear rubber suspension + V push device is highly reliable, the vehicle is laterally stable and smooth, and the vibration and noise reduction effect is good. Equipped with high-efficiency and energy-saving plunger pump and balance valve, using speed controllable variable amplitude self-weight lowering technology, automatic cooling system, and strong construction capacity. The machine can be equipped with a 9m extension arm, and can travel with the car (after being replaced with the jib). The maximum lifting height of main boom + extension boom + jib is 75.0m, which is equivalent to the lifting capacity of 90t-class cranes in the industry. Hoisting, luffing, slewing, and telescopic can be customized with slow-speed gear function, which is dedicated to precise hoisting. The machine is widely used in petrochemical, energy construction, transportation, municipal engineering, large ports, infrastructure construction and other construction fields Zoomlion QY80V truck crane technical parameters

This machine was manufactured in June 2016, Euro Ⅳ, 5-section boom, no big repair, normal maintenance, excellent performance, is your best choice.

Product Parameters:

Item QY80V
Working performance Max. rated gross lifting capacity (kg) 80000
Max. load moment of the basic boom (kN.m) 3116
Max. load moment of the longest main boom (kN.m) 1646
Max. lifting height of the basic boom (m) 13.7
Max. lifting height of main boom (m) 48.8
Max. lifting height of jib (m) 66.0
Max. lifting height of jib (m) 75.0
Working speeds Max. speed of single rope (main winch) (m/min) 130
Max. speed of single rope (auxiliary winch) (m/min) 110
Boom derricking up time (min) 62
Boom telescoping out time (s) 145
Rotation speed (r/min) 0-1.6
Traveling parameters Max. traveling speed (km/h) 75
Max. gradeability (%) 40
Min. turning diameter (m) ≤24
Min. ground clearance (mm) 280
Oil consumption per 100 km (L) 46
Weights Deadweight in traveling condition (kg) 50000
Complete vehicle kerb mass (kg) 49870
Front axle load (kg) 24000
Rear axle axle load (kg) 26000
Dimensions Dimensions (L×W×H) (mm) 15000×2850×3850
Longitudinal distance of outriggers (m) 6.38
Outrigger lateral distance (m) Full extension 8.0, half extension 5.28
Tail turning radius (mm) 4390
Main boom length (m) 12.5—48.0
Main boom elevation angle (°) -2- 80
Extended arm length (optional) (m) 9.0
Extension arm mounting angle (°) 0
Jib length (m) 10.3,17.5
Offset (°) 0,15,30

Used Zoomlion Crane 80 Ton Zoomlion QY80V Second Hand Truck Mobile CraneUsed Zoomlion Crane 80 Ton Zoomlion QY80V Second Hand Truck Mobile Crane
