Light Source: Main Lights: 5 * 120W RGBL LEDs (4-color, including Amber)
Outer Ring: 120 * 0.5W RGB LEDs (24 independently controllable segments)
Total Luminous Flux: Approx. 20,000 lm
Power / Voltage: 650W; AC 180–240V, 50/60Hz
Beam Angle: 3°–30° Linear Zoom (Ultra-narrow beam → Wide wash)
Field Angle: 4°–35°
Movement: 5 independently controllable heads (Pan/Tilt on X/Y axes); high-speed and smooth motion
Control: DMX512, RDM, Art-Net; independent channels per head; built-in macros, sound-activated mode
Effects: 5 independently controllable beams, outer pixel ring chasing effects, RGBL color mixing, strobe, linear CTO (2500K–8000K)
Protection Rating: IP66 (All-weather outdoor use; rain and dustproof)
Dimensions / Weight: 1000 * 230 * 180 mm; 30 kg
Mounting: Foldable mounting hooks + Quick-lock splicing buckles (for seamless horizontal linking of multiple units)
