XE300U Crawler Excavator Hydraulic Transmission 32700kg
XE300U Crawler Excavator Hydraulic Transmission 32700kg
Specifications
Brand Name :
XCMG
Model Number :
XE26U
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 unit
Price :
US$2000~US$35000
Payment Terms :
D/P, D/A, L/C, T/T
Supply Ability :
100 units +3weeks
Delivery Time :
3-5weeks
Packaging Details :
Standard export packaging
Max Reach At Ground Level :
11.6 m
Make :
HANGCHA
Machine Weight :
5000 KG
Max Digging Radius :
2500 mm
Unique Selling Point :
Fully hydraulic system
Hydraulic Valve Brand :
Other
Warranty :
1 Year
Overall Dimensions :
2m*3m*2.5m
Boom :
68m
Hydraulic Pump Brand :
Original brand
Rated Load :
20 Ton
Weight :
800kg
Description

Flexible and Durable XE300U Crawler Excavator with Hydraulic Transmission and 32700kg Operating Weight​

Basic Information

Model NO. XE300U Type Crawler Excavator
Usage Mining Excavator Bucket Shovel
Transmission Hydraulic Transmission Bucket Capacity 1.0~1.5m³
Certification CE Condition New
Transport Package Nude Package Specification 26500 KG
Trademark China Top 1 Brand Origin Xuzhou, Jiangsu, China
HS Code 87059091 Production Capacity 1000 Units/Month

Packaging & Delivery

Package Size 1014.00cm * 718.00cm * 720.00cm
Package Gross Weight 26500.000kg

Product Description

New-generation "U-series" small-sized short-tail excavatorsare flexible, efficient, reliable and durable. The engine emission meets the European V Standard and is energy-saving and environment-protective.
XE300U are more efficient and more reliable, and have high control precision, strong digging force, and excellent operational efficiency.
Exclusive load self-adaptive control technology ensures that the engine makes full use of every drop of fuel. More tools are provided to meet requirements of more complex working conditions and achieve the purpose of multiple functions in one machine.

Product Parameters

Sales model Unit XE300U
Operating weight Kg 32700
Bucket capacity m³ 1.4~1.6
Engine Model / QSB6.7
No. of cylinders / 6
Rated power kw/rpm 186/2000
Maximum torque/speed N.m/rpm 990/1500
Displacement L 6.7
Main performance Travel speed km/h 5.0/2.9
Swing speed r/min 9.8
Gradeability ° ≤35
Ground pressure kPa 44.7
Bucket digging force kN 201
Arm digging force kN 140
Maximum traction kN 262
Hydraulic system Rated flow of main pump L/min 2×266
Main safety valve pressure MPa 34.3/37
Travel system pressure MPa 34.3
Swing system pressure MPa 30
Pilot system pressure MPa 3.9
Oil Capacity Fuel tank capacity L 520
Hydraulic tank capacity L 270
Engine oil capacity L 30
Appearance size A Overall length mm 10645
B Overall width mm 3390
C Overall height mm 3500
D Width of platform mm 2960
E Track length mm 4945
F Overall width of chassis mm 3390
G Track width mm 800
H Wheel base of crawler mm 4030
I Track gauge mm 2590
J Counterweight clearance mm 1198
K Min. ground clearance mm 536
L Min. tail swing radius mm 3200
M Track height mm 1085
Working scope A Max. digging height mm 10145
B Max. dumping height mm 7180
C Max. digging depth mm 7200
E Max. vertical wall digging depth mm 5185
F Max. digging radius mm 10665
G Min. swing radius mm 3850
Standard Length of boom mm 6200
Length of arm mm 3110
Bucket capacity m³ 1.4
Optional Length of boom m³ 6200
Length of arm m³ 2650
Bucket capacity m³ 1.4(Rock bucket)
1.6(Earthwork bucket)
