High Resolution MIPI Camera Module FF 2K 1080P With 8MP IMX219 CMOS Sensor

8MP IMX219 2K 30fps MIPI CIS-2 Camera Module:

TYS-YF800W-V1 MIPI camera module with Sony IMX219 8MP high resolution 2K 30fps FF lens.8 million pixels can capture images and videos with rich details and high clarity, which can meet some scenes with certain requirements for image quality.

Factory wholesales 8 million IMX219 3296*2512 support 2K 30fps FF MIPI FPC camera module.Its pixel design and MIPI interface features result in relatively low module power consumption, while the smaller camera board size makes it easy to integrate into various devices with limited space.Pairing with distortion free lenses can make the captured images more realistic.

Specification:

Technical & Mechanical:

• Power Supply: AVDD: 2.8 V

  DVDD: 1.2V

  IOVDD: 1.8 V

• Operating Temperature: -20°C to +70°C
• Stable image: 0°C to +60°C
• Module Size : 12.5*180*5.35mm
• 2-wire serial communication circuit on chip
• High sensitivity,low dark current,no smear

IMX219 8MP 3296*2512 MIPI FPC camera module application scenarios:

Sony IMX219 8MP high definition 2K 1080P 30fps MIPI camera module for Autonomous robot system.The imaging capability and MIPI interface transmission characteristics of the module can help the robot obtain external environmental image information, facilitating autonomous navigation, obstacle avoidance, target recognition and other tasks.

On sales MIPI CSI-2 camera module smartphones tablets and notebook with 8 million IMX219 3296*2512 CMOS image sensor.The IMX219 image sensor itself has a small size, and the MIPI camera module based on it can also be made more compact, which is conducive to the lightweight design of smartphones and tablets, especially for front facing cameras. Its small size feature can adapt well to the current trend of narrow bezel design.

Best quality 8-megapixel 4K 2K FF wide angle high sensitivity MIPI CSI-2 camera module with IMX219 CMOS sensor and MIPI interface are compact in size and have low power consumption, making them suitable for miniaturized robots such as desktop robots and micro inspection robots, avoiding excessive space occupation or excessive battery life consumption.

1/4 inch IMX219 4K 2K resolution 30fps MIPI camera module is also relatively compact in size. which makes it easy to integrate it into various forms of access control equipment. Whether it is a traditional standalone access control machine or an embedded access control device integrated with building intercom systems, it can be easily embedded in the module without making significant changes to the appearance and internal structure of the equipment.
