Specifications
Model Number :
Aluminum Foil with PP Woven Fabrics Film
Brand Name :
UPASS
Place of Origin :
Shanghai, China
MOQ :
10000
Price :
$0.40-0.45
Thickness :
85/90/custom gsm
Type :
Roll
Use :
Insulation Material, Liner & Wad
Logo printing :
Custom logo
Treatment :
Coated, Composited
Color :
Blue/Grey/Custom
Width :
1350/1380±5mm,custom
gsm :
85/90/custom
Product Name :
Aluminum Foil with PP Woven Fabrics Film
Usage :
Building thermal insulation
Composite method :
Solvent-based/Solvent-free/Coating
Flame retardant :
Optional
Description
Radiant Barrier Insulation Aluminum Foil Reinforced PP Woven Fabric Roll
Product Overview
This high-performance building insulation material combines a high-purity aluminum foil reflective layer with strong polypropylene (PP) woven fabric through advanced lamination. It provides superior radiant heat reflection, tear resistance, and moisture protection as a complete insulation system for industrial and commercial applications.
Key Advantages
  • Energy Efficiency: Reflects radiant heat to reduce cooling costs in summer and retains indoor heat in winter
  • Durability: Exceptionally tough construction resists trampling and damage during installation
  • Dual Barrier Protection: Provides both thermal insulation and vapor/moisture barrier functions
  • Environmental Safety: Meets environmental standards with no fiber shedding
  • Versatile Applications: Suitable for metal roofs, steel structures, concrete walls, and cold storage facilities
Available in 85 GSM, 90 GSM, or Custom Thickness Options
Technical Specifications
Characteristic Value Standard
Width 1350mm +/-5 Supplier specification
Grammage 85g/m² +/-5 Supplier specification
Denier 750D/850D Supplier specification
Mesh 8X6 Supplier specification
Color Silver Grey Supplier specification
UV Resistance 2.5% Supplier specification
Tensile Strength - MD 12.5 N/50mm AS1301.448
Tensile Strength - TD 7.5 N/50mm AS1301.448
Elongation - MD 1.8% Supplier specification
Elongation - TD 1.8% Supplier specification
Winding 5,000 LMT/Roll Supplier specification
Core Size 76mm Supplier specification
Flammability Index Low ≤5 AS 1530.2
Edge Tearing Resistance Min 80 AS/NZS 4200.1
Application&Product Images

Industrial and commercial buildings: Thermal insulation and moisture-proofing for steel structure factory roofs and walls.

Civil buildings: Reflective insulation layers for residential attics and under-pitched roofs; external or internal moisture-proof and thermal insulation layers for exterior wall insulation systems.

Special environments: Moisture-proof, vapor-proof, and thermal insulation layers for cold storage warehouses and storage facilities; external protective layers for pipe insulation.

Agricultural facilities: Nighttime insulation and summer shading for greenhouses.

Radiant Barrier Insulation Roll with Aluminum Foil Reinforced PP Woven Fabric - 85/90/Custom GSM, Corrosion Resistant, Flame Retardant Radiant Barrier Insulation Roll with Aluminum Foil Reinforced PP Woven Fabric - 85/90/Custom GSM, Corrosion Resistant, Flame Retardant Radiant Barrier Insulation Roll with Aluminum Foil Reinforced PP Woven Fabric - 85/90/Custom GSM, Corrosion Resistant, Flame Retardant Radiant Barrier Insulation Roll with Aluminum Foil Reinforced PP Woven Fabric - 85/90/Custom GSM, Corrosion Resistant, Flame Retardant Radiant Barrier Insulation Roll with Aluminum Foil Reinforced PP Woven Fabric - 85/90/Custom GSM, Corrosion Resistant, Flame Retardant Radiant Barrier Insulation Roll with Aluminum Foil Reinforced PP Woven Fabric - 85/90/Custom GSM, Corrosion Resistant, Flame Retardant
