Specifications
Brand Name :
UF
Model Number :
508
Place of Origin :
CHINA
MOQ :
10000SQM
Payment Terms :
L/C, T/T
Supply Ability :
20 Tons/Month
Delivery Time :
5-7 working days
Packaging Details :
Bubble or Film Wrap
Product name :
Anti-aging PET laminated film for Packaging Film
Material :
Aging Resistance PET
Aging Resistance Time :
About 25 Years
Structure :
Fluorine film+ PET Film
Thickness :
0.128mm
Application :
surface material of waterproofing membranes and tapes
Description

Anti-aging PET laminated film Packaging film

Description:

It is specially designed for waterproofing industry, which shall substitute conventional exposed waterproofing material including the film for waterproofing membrane. It also has cost effectiveness , and lasts over 25years of weather resistance.

Application: It is used as surface material of waterproofing membrane.

Main features: Excellent properties of anti-aging, UV resistance, weather resistance and chemical corrosion resistance. Resistance to high temperature,heat,humidity and extreme cold. Reflectivity of over 85%.

Color: White

Performance index:

Test item Test method Value Remark
Thickness UF508 GB/T6672-2001 / 0.12mm
Width GB/T6673-2001 / As per requirements
Sleeve I.D. 76mm
Max. Tensile strength UF508 GB/T 328.9-2007

MD:770N

TD:762N

 Rectangle Specimen-Width: 25mm, Stretching speed: 100mm/min., Fixture gauge length: 100mm
Elongation @ Max.tension UF508

MD:79%

TD:99%
Peeling force UF508 GB/T 529-2008

MD:23N

TD:21N

 Stretching speed:250mm/min
Surface tension GB/T14216 ≧42dyn/cm Dyne pen test
Rate of dimensional changes UF508 GB/T 35467-2017

MD:0%

TD:0%

 90℃&24h

MVTR

 GB/T 21529 ≦70 g/m2.24h (20um)

38℃+100%RH

Electroanalysis sensor
Flame retardant rating UL94 VTM-0

Weather resistance film

(White)
Aging test PCT96 /

Yellowing index △b≤2.0,

Temperature:121℃,

Humidity: 100％,

Atmosphere pressure: 2atm,Time: 48h
UV300KWh IEC61215 The sample temperature is 60±5℃, and the total irradiation amount is 120KWh•m2, of which UVB accounts for 3%-10%.
DH2000h IEC61215 Temperature 85℃, humidity 85%R.H., 2000h
TC400 IEC61215 Temperature -40℃～85℃, 6h/cycle, 400 cycles
