Green 0.09mm Waterproof Thermal HDPE Plastic Film
Green 0.09mm Waterproof Thermal HDPE Plastic Film
Green 0.09mm Waterproof Thermal HDPE Plastic Film
Green 0.09mm Waterproof Thermal HDPE Plastic Film
Green 0.09mm Waterproof Thermal HDPE Plastic Film
Green 0.09mm Waterproof Thermal HDPE Plastic Film
Green 0.09mm Waterproof Thermal HDPE Plastic Film
Green 0.09mm Waterproof Thermal HDPE Plastic Film
Specifications
Place of Origin :
China
Brand Name :
Upass
Certification :
CE, ROHS
Model Number :
Cross Laminated Film
MOQ :
Negotiable
Price :
Negotiable
Packaging Details :
Bubble Wrap & Wooden Pallet
Delivery Time :
15days
Payment Terms :
T/T,L/C
Supply Ability :
200,000㎡~300,000㎡
Product Name :
Construction Waterproofing Application Cross Laminated Film
Material :
HDPE
Production Process :
Cross Laminated
Performance :
Thermal Dimensional Stability
Thickness :
0.09-0.26
Width :
100-1250mm
Color :
Black, Grey, Blue, Green, etc.
Application :
Underlayment, Waterproofing membrane
Printing :
Can be customizable
Sample :
Available
Description

Construction Waterproofing Application Cross Laminated Film​

Description:

It is a high-strength multi-layer composite film,It is made of HDPE as the base material,

adding plasticizer, plasticizer, stabilizer, antioxidant, UV absorber, toughener and other

additives through multi-layer co-extrusion blow molding into embryos, and then by multiple

pull Stretching, then rotary cutting into a film substrate with a horizontal and vertical

distribution of 45 °, and finally through cross-compositing. Due to its cross-stacking

structure is different from ordinary single-layer or multi-layer film, it has the thermal stability,

dimensional stability, two-way tear resistance, two-way uniform tension and high elongation

which are not available in traditional films.

NO. Item Performance
SDM-30 SDM-60
1 Tensile Property Tensile Strength/Mpa ≥ 30 50
MaxF/(N/50mm) ≥ 200 300
Elongation as MaxF/% ≥ 200
Elongation at break/% ≥ 250
2 Sample number of no broken tested by free-falling dart method ≥ 8
3 Tear Strength(Nail Shank)/N ≥ 60
4 Angle Tear Strength/N ≥ 25
5 Thermal Stability 120 ℃,10min, No bulb, No deformation
6 Cryogenic Flexibility ℃

-35℃,

No fissure, No delamination
7 Thermal Ageing Appearance No bulb, No deformation
Subsequent MaxF/% ≥ 80
Elongation at MaxF/% ≥ 200
Elongation at break/% ≥ 200
8 Artificial Weathering Appearance No bulb, No deformation
Subsequent MaxF/% ≥ 70
Elongation at MaxF/% ≥ 180
Elongation at break/% ≥ 180


Construction Waterproofing Application Cross Laminated Film Advantages:

  • Cross Laminated process
  • Puncture Resistance: less accidental damage
  • Thermal Dimensional Stability: No fish-mouthing or controlled shrinkage
  • Cold temperature resistant down to -30°C/-20°C
  • Cross laminated film allows waterproofing membranes to bridge gaps in
  • sheathing and is resistant to damage from incidental movement and settling
  • of the roof
  • UV Stability for typical job site exposure


Application:

Waterproofing Membranes:
Green 0.09mm Waterproof Thermal HDPE Plastic Film

Construction:


Green 0.09mm Waterproof Thermal HDPE Plastic Film


FAQ:

Green 0.09mm Waterproof Thermal HDPE Plastic Film
