High Strength HDPE Film Anti Skid Cross Laminated Film
High Strength HDPE Film Anti Skid Cross Laminated Film
High Strength HDPE Film Anti Skid Cross Laminated Film
High Strength HDPE Film Anti Skid Cross Laminated Film
High Strength HDPE Film Anti Skid Cross Laminated Film
High Strength HDPE Film Anti Skid Cross Laminated Film
Specifications
Brand Name :
Upass
Model Number :
High Strength Film
Certification :
CE, ROHS
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T,L/C
Supply Ability :
200,000㎡~300,000㎡
Delivery Time :
15days
Packaging Details :
Bubble Wrap & Wooden Pallet
Product Name :
Anti-skid High Strength HDPE Film Antiskid Cross Laminated Film
Material :
HDPE
Production Process :
Lamination
Performance :
Anti-slip, Anti-skid, Antiskid
Thickness :
0.12-0.26
Width :
900-1150mm
Color :
Black, Grey, Blue, Green, etc.
Application :
Underlayment, Waterproofing membrane and tapes
Printing :
Can be customizable
Sample :
Available
Description

Anti-skid High Strength HDPE Film Antiskid Cross Laminated Film

Anti-skid High Strength HDPE Film Description:

It is a high-strength multi-layer composite film,It is made of HDPE as the base material, adding plasticizer, plasticizer, stabilizer, antioxidant, UV absorber, toughener and other additives through multi-layer co-extrusion blow molding into embryos, and then by multiple pull Stretching, then rotary cutting into a film substrate with a horizontal and vertical distribution of 45 °, and finally through cross-laminated.

It has the thermal stability, dimensional stability, two-way tear resistance, two-way uniform tension and high elongation which are not available in traditional films.

The surface special handling, rough surface, not smooth, make it anti-slip function. Mainly application for self-adhesive membranes, tapes and underlayment for pitched-roof.


Anti-SKID High Strength HDPE Film Parameter:

NO. Item Performance
SDM-30 SDM-60
1 Tensile Property Tensile Strength/Mpa ≥ 30 50
MaxF/(N/50mm) ≥ 200 300
Elongation as MaxF/% ≥ 200
Elongation at break/% ≥ 250
2 Sample number of no broken tested by free-falling dart method ≥ 8
3 Tear Strength(Nail Shank)/N ≥ 60
4 Angle Tear Strength/N ≥ 25
5 Thermal Stability 120 ℃,10min, No bulb, No deformation
6 Cryogenic Flexibility ℃

-35℃,

No fissure, No delamination
7 Thermal Ageing Appearance No bulb, No deformation
Subsequent MaxF/% ≥ 80
Elongation at MaxF/% ≥ 200
Elongation at break/% ≥ 200
8 Artificial Weathering Appearance No bulb, No deformation
Subsequent MaxF/% ≥ 70
Elongation at MaxF/% ≥ 180
Elongation at break/% ≥ 180

Anti-slip High Strength HDPE Film Advantages:

High Strength HDPE Film Anti Skid Cross Laminated Film


Structure of bitumen membranes:

High Strength HDPE Film Anti Skid Cross Laminated Film
