High Precision 180 Degree Tape Peel Strength Tester Peeling Test Equipment
High Precision 180 Degree Tape Peel Strength Tester Peeling Test Equipment
High Precision 180 Degree Tape Peel Strength Tester Peeling Test Equipment
High Precision 180 Degree Tape Peel Strength Tester Peeling Test Equipment
High Precision 180 Degree Tape Peel Strength Tester Peeling Test Equipment
High Precision 180 Degree Tape Peel Strength Tester Peeling Test Equipment
Specifications
Brand Name :
KINSGEO
Model Number :
KJ-1065A
Certification :
CE/ISO
Place of Origin :
China
MOQ :
1 set
Price :
USD/3800/SET
Payment Terms :
T/T,D/A
Supply Ability :
30Sets/month
Delivery Time :
15 work days
Power :
AC220V 50Hz
Usage :
Universal Testing Machine
Weight :
90kg
Product name :
Computer control single column universal testing machine
Power supply :
can be customized
Application :
universal tester
Standard :
BS.EN.ASTM
Motor :
Panasonic Servo Motor
Warranty :
1 Year
Accuracy :
+/-0.5%
Name :
electronic universal testing machine
Capacity :
20
Stroke :
650mm(excluding clamp)
Resolution :
1/250
Tester resolution :
constant the resolution
Operation :
Computer windows operation
Description

  • KJ-1065A Computerized Servo Peel Strength Tester

    Application: Equipped with various fixtures, this machine can perform 90-degree peel strength, 180-degree peel strength, and release force tests for adhesive tapes and self-adhesive labels. It is used to evaluate the adhesion performance of adhesive products. It can also test the tensile strength of various substrates. Additionally, the instrument can be edited via software operation to conduct pressure tests, tensile tests, and other types of experiments.

    Testing Accuracy: The minimum measurable value is 0.5g/25mm, which effectively improves the quality level of products in the electronic materials industry such as adhesive tapes, protective films, release papers, and release films.

    Compliant Standards: ASTM D3330, FINAT, GB/T2792, PSTC

    Technical Specifications:

    Capacity: 5KG (0.5g-4500g)

    Accuracy Class: 0.5 grade

    Maximum Load: 5KG

    Effective Measuring Range: 0.02/100-100%

    Effective Test Width: 100mm

    Effective Stroke: 650mm

    Test Speed: 0.5~500mm/min

    Speed Accuracy: Within ±0.5% of the indicated value

    Displacement Measurement Accuracy: Within ±0.5% of the indicated value
Technical Specifications
Design Standards ASTM D903, GB/T2790/2791/2792, CNS11888, JIS-K6854, PSTC7
Model KJ-1065A
Capacity 5kg (optional)
Stroke 650mm
Speed Range 50-400mm/min adjustable, constant speed, 300mm/min
Test Space 120mm MAX
Accuracy ±0.5%
Resolution 1/50,000
Motor Adjustable speed motor
Display Force and elongation display
Dimensions (W×D×H) 50×50×120cm
Optional Accessories Stretcher, air clamp
Weight 60kg
Power 1PH, AC220V, 50/60Hz
