Programmable LCD Touch Screen Static Shear Force Tester with Stainless Steel SUS 304 and Customizable Temperature Range
Programmable LCD Touch Screen Static Shear Force Tester with Stainless Steel SUS 304 and Customizable Temperature Range
Programmable LCD Touch Screen Static Shear Force Tester with Stainless Steel SUS 304 and Customizable Temperature Range
Programmable LCD Touch Screen Static Shear Force Tester with Stainless Steel SUS 304 and Customizable Temperature Range
Specifications
Brand Name :
KINSGEO
Model Number :
KJ-2091
Certification :
ISO, CE and etc.
Place of Origin :
CHINA
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
100 sets per month
Delivery Time :
20 days after order
Packaging Details :
Plywood box
Product name :
Programmable Temperature & Humidity Test Chamber
Control range of temperature :
-70℃～150℃ （Customizable）
Control range of humidity :
RH20%～98%
Controller :
Programmable LCD touch screen
Temperature fluctuation :
±0.5℃
Inside material :
Stainless steel SUS 304 #
Size :
Customized
Warranty :
12 Months
Description

Reference standards: GB/T4851, CNS-11887, 11888, PSTC-7
Usage: The KJ-6014D non-contact high/low temperature adhesive retention tester is widely used in the adhesive products industry such as adhesive tapes, protective films, self-adhesive materials, labels, foam, adhesives, etc., for testing the adhesive retention of adhesive tapes under certain temperatures. The oven-type adhesive retention force tester measures the ability of the adhesive tape adhered to the test plate according to the specified method under certain set temperature and humidity, high and low humidity conditions to resist displacement under the specified gravity along the length direction. The adhesive retention of the adhesive tape is represented by the time it takes for the test piece to move a certain distance (or completely detach) within a certain time period after being moved a certain distance (or completely detached).
Specification parameters:
Internal dimensions: 50x75x60CM
Volume: 225L
Temperature range: -40～150℃
Humidity range: 20%～98%RH
Temperature and humidity distribution accuracy: ±2℃ ±3%RH
Temperature and humidity stability: ±0.3℃ ±2.5%RH
Heating speed: -20℃～100℃ approximately 25 minutes
Cooling speed: 20℃～-40℃ approximately 60 minutes
Freezing system: 1. Compressor: Original imported fully sealed compressor from France
2. Refrigerant: Environmentally friendly refrigerant
3. Condenser: Air-cooled condenser
4. Other accessories: Desiccant, oil separator, high and low pressure repair valve, protection switch
5. Expansion system: Capacity-controlled refrigeration system
Temperature display: 0.1℃ unit display.

Programmable LCD Touch Screen Static Shear Force Tester with Stainless Steel SUS 304 and Customizable Temperature Range

Programmable LCD Touch Screen Static Shear Force Tester with Stainless Steel SUS 304 and Customizable Temperature Range
