UV weathering test chamber
UV weathering test chamber
UV weathering test chamber
UV weathering test chamber
UV weathering test chamber
UV weathering test chamber
UV weathering test chamber
UV weathering test chamber
Specifications
Brand Name :
Dongjun
Model Number :
DJ-26-25
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
500pcs
Delivery Time :
15-25Work days
Packaging Details :
Wooden crate packaging
Outside size :
395×895×550mm
Inside size :
75mm×150mm×(0.6)mm
Total power :
1.25kw
Machine weight :
48kg
Temperature range :
Room temperature ~ 120℃
Description

UV weathering test chamber

Product Overview:

This device is suitable for water exposure aging tests of non-metallic materials such as coatings. Since ultraviolet rays in sunlight are the main factor causing oxidative degradation of polymers, and moisture is an important destructive factor that accelerates aging, this device features quick and simple simulation of outdoor exposure aging, and is of practical value for testing the relative weather resistance of different test specimens.




Parameters

Parameter Item

Specification

Outside size

395×895×550mm

Inside size

75mm×150mm×(0.6)mm

Setting range of test time

0.01s~99.99s/0.1h~999.9h

Timing range of spraying duration

1s~99min59s/1min~9999min

Temperature range


RT～60℃

Nominal peak wavelength of ultraviolet light

313nm(91.5kcal/gmol)

Power of UV Fluorescent Tube

0.02kw×3

Rotating diameter of the specimen turret

Ø 189～Ø 249 mm

Rotational speed of the sample turret

3.7cp.m

Drive motor speed

1250r.p.m

Water pump power

0.08kw

Water pump flow rate

47 L/min

Total power

1.25kw
Machine weight (kg)

48kg
Rated service life of the lamp tube
1000h


UV weathering test chamber


UV weathering test chamber



UV weathering test chamber

UV weathering test chamber


Company Profile

UV weathering test chamber

PACKING AND TRANSPORTATION

UV weathering test chamber

UV weathering test chamber

FAQ

How to install and use the product?

The product is shipped with an operating instructions and video of English version.or we will send you an operation video to teach you how to install and use the product with English speaking. However, if you need us to teach you face to face, please let us know in advance.

How about the packing for machine, is it safely protected during transportation?
Our machine is packed by standard export wooden box, it won’t be damaged. We’ve delivered many testing machines abroad by sea or by air without damage.
