V8 Mini R32 VRF System 4-48HP Compact Eco-Friendly R32 Refrigerant 67% Lower GWP Small Footprint Compact Efficient Environmentally Responsible
V8 Mini R32 VRF System 4-48HP Compact Eco-Friendly R32 Refrigerant 67% Lower GWP Small Footprint Compact Efficient Environmentally Responsible
V8 Mini R32 VRF System 4-48HP Compact Eco-Friendly R32 Refrigerant 67% Lower GWP Small Footprint Compact Efficient Environmentally Responsible
V8 Mini R32 VRF System 4-48HP Compact Eco-Friendly R32 Refrigerant 67% Lower GWP Small Footprint Compact Efficient Environmentally Responsible
Specifications
Brand Name :
Hongtai，Midea
Certification :
CB, ISO
Place of Origin :
China
Product Name :
V8 Mini R32 VRF System
Capacity Range :
4-48HP (Combined) / 4-16HP (Single Unit)
Power Supply :
380-415V / 3Ph / 50Hz (220V optional)
Cooling Capacity :
11.2kW - 45kW (Single Unit)
Heating Capacity :
12.5kW - 50kW (Single Unit)
Refrigerant :
R32 (67% lower GWP than R410A)
IEER :
7.00 - 8.50
SEER :
6.80 - 8.20
Description
V8 Mini R32 VRF System: Compact Eco-Friendly Solution
The V8 Mini R32 series brings advanced VRF technology to smaller commercial applications with environmentally conscious design. Featuring R32 refrigerant with 67% lower global warming potential compared to traditional R410A, this compact system delivers full VRF performance while minimizing environmental impact.
System Overview
Perfect for small-to-medium commercial buildings, retail spaces, restaurants, and multi-family residential projects, the V8 Mini delivers the same advanced technology as the full-size V8 series but scaled for smaller applications. The R32 refrigerant not only reduces environmental impact but also improves system efficiency, delivering IEER ratings up to 8.5.
Key Features
  • R32 Refrigerant Technology: 67% lower GWP (675 vs 2088 for R410A) with improved heat transfer characteristics for higher system efficiency and reduced energy consumption
  • Compact Footprint Design: 30% smaller than equivalent V8 Pro units, ideal for space-constrained installations with reduced structural reinforcement requirements
  • Full V8 Technology: Includes DC inverter compressor technology, advanced electronic expansion valves, intelligent defrost logic, and comprehensive self-diagnostic capabilities
  • Flexible Piping: Optimized for retrofit projects with reduced piping diameter requirements and simplified branch piping
  • Smart Control System: Dedicated mini-system controller with smartphone app control, weekly scheduling, energy monitoring, and support for up to 32 indoor units
Applications
  • Small-to-Medium Office Buildings (Under 5,000 sqm floor area)
  • Retail Chain Stores with eco-friendly credentials
  • Restaurants & Food Service facilities with zoned comfort
  • Multi-Family Residential buildings and condominiums
  • Healthcare Clinics requiring precise temperature control
  • Educational Facilities including schools and training centers
Technical Specifications
Parameter Specification
Capacity Range 4-48HP (Combined) / 4-16HP (Single Unit)
Cooling Capacity 11.2kW - 45kW (Single Unit)
Heating Capacity 12.5kW - 50kW (Single Unit)
Refrigerant R32 (67% lower GWP than R410A)
IEER 7.00 - 8.50
SEER 6.80 - 8.20
Power Supply 380-415V / 3Ph / 50Hz (220V optional)
Footprint Reduction 30% smaller than equivalent V8 Pro
Maximum Piping Length 300m total / 120m equivalent
Vertical Separation 50m
Indoor Units per System Up to 32
Combination Ratio 50%-130%
Operating Range (Cooling) -5°C to 46°C
Operating Range (Heating) -15°C to 24°C
Certifications & Standards
Eurovent Certified Performance, CE Marking, F-Gas Regulation Compliant, ERP Energy Efficiency Compliant, RoHS Compliant, UL Safety Certified
