Floor Standing AC Modern Design for Commercial Spaces Multiple Styles Available 2.2-14.0kW
Floor Standing AC Modern Design for Commercial Spaces Multiple Styles Available 2.2-14.0kW
Floor Standing AC Modern Design for Commercial Spaces Multiple Styles Available 2.2-14.0kW
Floor Standing AC Modern Design for Commercial Spaces Multiple Styles Available 2.2-14.0kW
Specifications
Capacity Range :
2.2 - 14.0 kW (7.5 - 47.8 kBtu/h)
Cooling Capacity :
2.2 - 14.0 kW
Power Supply :
1-phase, 220-240V, 50Hz
Airflow Rate :
473 - 1054 m³/h (7 speeds)
Sound Pressure Level :
29 - 57 dB(A)
Heating Capacity :
2.4 - 16.0 kW
Refrigerant Type :
R410A/R32
Brand Name :
Hongtai，Midea
Model Series :
MIH-F3N18 / MIH-F4N18 / MIH-F5N18
Place of Origin :
China
Product Name :
Floor Standing Units
Certification :
CB, ISO
Net Dimensions (W×H×D) :
915-1253×470-566×200 mm/1020-1360×495-591×200 mm
Description
Floor Standing AC Modern Design for Commercial Spaces

Multiple styles available with capacity range of 2.2-14.0kW for versatile commercial applications.

Product Overview

The V8 Floor Standing Units deliver exceptional heating and cooling performance with three distinct design styles to complement any interior aesthetic. The F3 concealed design blends seamlessly into any space, the F4 front air intake offers easy filter access, while the F5 underside air intake provides a sleek, modern appearance.

All models feature DC fan motor and water pump technology for whisper-quiet operation and maximum energy efficiency. The 7-speed DC fan motor provides extensive customization options for optimal comfort, while the digital display and alert beep can be deactivated for night-time comfort.

The air filter monitoring system provides real-time detection of filter resistance with blockage level display from 10-100%, enabling proactive maintenance. With external static pressure of 0-60Pa for F3/F4 models and 0-10Pa for F5, these units offer flexible installation options for various ceiling configurations and duct layouts.

Key Features & Benefits
  • Capacity Range: 2.2 - 14.0 kW (7.5 - 47.8 kBtu/h) for versatile applications
  • Three Design Styles: F3 (Concealed), F4 (Front Air Intake), F5 (Underside Air Intake)
  • 7 Fan Speeds: Customizable comfort settings to meet diverse user preferences
  • DC Fan Motor & Water Pump: Quieter operation and improved energy efficiency
  • Air Filter Monitoring: Real-time detection of filter resistance with blockage level display (10-100%)
  • 0.5°C/1°C Temperature Control: Precise temperature adjustment for optimal comfort
  • Digital Display On/Off: Display can be deactivated for night-time comfort
  • Alert Beep On/Off: Deactivate alert sounds to prevent disturbance
  • External Static Pressure: 0-60 Pa (F3/F4), 0-10 Pa (F5) for flexible installation
Recommended Applications
  • Commercial spaces with limited ceiling access
  • Retail stores and showrooms
  • Restaurants and cafes
  • Gyms and fitness centers
  • Server rooms requiring precise temperature control
  • Historical buildings with restrictions on ceiling modifications
Certifications & Standards
  • ISO 9001:2015 Quality Management System
  • ISO 14001:2015 Environmental Management System
  • CE Certification for European Market
  • ERP (Energy-related Products) Directive Compliance
  • RoHS (Restriction of Hazardous Substances) Compliant
  • IEC 60335 Safety Standards
Technical Specifications
Parameter Specification
Model Series MIH-F3N18 / MIH-F4N18 / MIH-F5N18
Capacity Range 2.2 - 14.0 kW (7.5 - 47.8 kBtu/h)
Power Supply 1-phase, 220-240V, 50Hz
Cooling Capacity 2.2 - 14.0 kW
Heating Capacity 2.4 - 16.0 kW
Airflow Rate (F3) 473 - 1054 m³/h (7 speeds)
Airflow Rate (F4/F5) 498 - 1054 m³/h (7 speeds)
Sound Pressure Level 29 - 57 dB(A)
Net Dimensions F3 (W×H×D) 915-1253×470-566×200 mm
Net Dimensions F4/F5 (W×H×D) 1020-1360×495-591×200 mm
Refrigerant Type R410A/R32
