Specifications
Certification :
CB,ISO
Cooling Capacity Range :
94.6-565.6 RT (332.6-1,988 kW) 90-550+ RT
IPLV :
8.085 8.0+
Brand Name :
OEM;MIDEA
Product Name :
Water Cooled Screw Chiller
COP :
5.534 5.5+
Refrigerant :
R134a R513A (VFD) / R134a (Fixed)
Place of Origin :
China
Compressor Type :
Semi-Hermetic Twin-Rotor Screw
Bearing :
SKF, 50,000+ Hour Rated Life
Description
Midea Water Cooled Screw Chiller - 330 to 1990 kW
Advanced water-cooled screw chiller platform featuring COP 5.5 efficiency, AHRI 550/590 certification, and semi-hermetic screw compressors with SKF bearings designed for 50,000+ hour service life.
Investment Overview
Water-cooled chiller economics offer higher initial investment but significantly lower operating costs per kilowatt. The Midea platform includes two complementary series: SHWE (R134a, fixed-speed, 94.6-565.6 RT / 332.6-1,988 kW, COP 5.534, IPLV 8.085) and SCWG (R513A variable-speed + R134a fixed-speed, 90-550+ RT).
The SHWE series excels in stable cooling applications like hospitals and industrial processes, delivering optimal lifecycle costs. The SCWG series provides variable-frequency operation for fluctuating demand, achieving 20-30% part-load efficiency improvements with 2-3 year payback periods.
Both series feature semi-hermetic twin-rotor screw compressors with SKF bearings rated for 50,000+ operating hours, eliminating 2-3 major compressor overhauls over a 25-year lifespan. Stepless capacity regulation maintains 65 dB(A) at part load for quiet operation in sensitive environments.
Total Cost of Ownership Advantages
  • COP 5.534 / IPLV 8.085 (SHWE) - Full-load and part-load efficiency leaders reducing annual cooling costs by 25-35%
  • SKF Bearing, 50,000+ Hour Life - Eliminates 2-3 compressor overhauls, saving $80,000-150,000 per unit
  • Semi-Hermetic Twin-Rotor Screw - Field-serviceable design reduces overhaul costs by 40-60%
  • Stepless Capacity Regulation - Continuous modulation from 100% to 12.5% with 65 dB(A) part-load noise
  • R513A Variable-Speed Option (SCWG) - Forward-compatible with F-Gas regulations and 20-30% part-load efficiency improvement
  • Compact Footprint - 30-40% smaller than equivalent air-cooled units, maximizing valuable floor space
  • 65 dB(A) Part-Load Noise - Suitable for installation near occupied spaces without acoustic enclosures
Project Applications
Hospital & Healthcare Campus (500-2,000 RT)
SHWE fixed-speed series handles baseload efficiently while SCWG variable-speed units cover peak demand. Combined plant IPLV of 8.0+ reduces annual cooling energy costs by $60,000-180,000 with 1.5-2.5 year payback.
Industrial Process Cooling
50,000-hour SKF bearing life ensures reliability with minimal interventions. Stepless capacity regulation maintains process water temperature within ±0.3°C, preventing production losses of $20,000-100,000 annually.
Commercial High-Rise Buildings
Compact design recovers valuable basement space worth $30,000-150,000 in leasable area per unit over 25-year holdings.
District Energy & Central Energy Stations
SCWG variable-speed units maintain system IPLV above 7.5 at 40-80% load, achieving 30-40% energy cost savings with 2-3 year payback.
Certifications
  • AHRI 550/590 - Performance and IPLV rating certification
  • Eurovent - Independent European performance verification
  • CE Marking - European Economic Area conformity
  • GB Standards - Chinese national energy-efficiency compliance
Technical Specifications
Parameter SHWE (R134a Fixed-Speed) SCWG (R513A VFD + R134a Fixed)
Cooling Capacity 94.6-565.6 RT (332.6-1,988 kW) 90-550+ RT
Refrigerant R134a R513A (VFD) / R134a (Fixed)
Compressor Type Semi-Hermetic Twin-Rotor Screw Semi-Hermetic Twin-Rotor Screw
Bearing SKF, 50,000+ Hour Rated Life SKF, 50,000+ Hour Rated Life
COP 5.534 5.5+
IPLV 8.085 8.0+
Capacity Regulation Stepless 100%-12.5% Stepless 100%-12.5%
Part-Load Noise 65 dB(A) 65 dB(A)
Certifications AHRI 550/590, Eurovent AHRI 550/590, Eurovent
Why Choose Hongtai
  • System-Level Design Review - Comprehensive condenser-water loop evaluation to ensure rated COP performance
  • Bearing-Life Documentation - SKF bearing traceability certificates and life calculations for asset management
  • Commissioning & Performance Testing - On-site or remote support with calibrated performance verification
  • 25-Year Lifecycle Cost Modeling - Detailed TCO analysis comparing Midea options against competing brands
  • Spare-Parts Forward-Stocking - Pre-positioned compressor components for minimal repair time
