Specifications
Certification :
CB,ISO
Cooling Capacity :
5,300-86,000W
Refrigerant :
R134a (compatible: R1234ze, R513A, R515B)
Capacity Range :
8-134HP
IEER :
IEER 9.6
Climate Rating :
T3 — 52 deg C full-capacity cooling, zero derating
Positioning :
Flagship Full DC VRF — Contractor's Platform
Power Supply :
Dual frequency 50/60Hz, 180-440V, generator compatible
Place of Origin :
China
Product Name :
V8 Pro
Brand Name :
OEM;MIDEA
Description
VRF Contractor Pick 8-134HP T3 52°C IEER 9.6 R32
One Platform from Studio Fit-Out to Tower Commissioning
Product Overview
The V8 Pro VRF system is engineered to eliminate the challenges contractors face with complex projects. From desert hospitals requiring full capacity at peak ambient temperatures to mixed-use towers with changing scope requirements, this platform delivers consistent performance across all conditions.
Spanning 8 to 134HP from a single outdoor platform, the V8 Pro eliminates the need for multiple product families. Whether handling a 10HP boutique retail fit-out or a 134HP commercial high-rise, the same control logic, remote access app, commissioning procedures, and spare parts apply throughout the capacity range.
With T3-rated 52°C full-capacity cooling and an IEER of 9.6, this system ensures zero-callback installations that exceed owner expectations and build your reputation with every completed project.
Key Features
True T3 Capacity – 52°C, No Derating
Maintains full nameplate cooling output at 52°C outdoor temperature without capacity reduction, validated across hundreds of desert climate installations.
  • Full nameplate cooling output at 52°C with no capacity reduction
  • Oversized microchannel condenser coils for maximum heat rejection
  • High-flow axial fans with aerodynamically shaped blades
  • Compressor rated for elevated discharge pressures
  • Eliminates the need for oversizing equipment
One Platform, 8-134HP – Simplified Operations
A single platform covering the entire capacity range with identical control architecture, mobile app, error codes, and service procedures.
  • One control platform covers 8-134HP range
  • Reduced training requirements for crews
  • Simplified spare parts inventory management
  • Identical mobile commissioning app across all models
  • Flexible crew assignment across concurrent projects
Full DC Inverter Chain – Up to 40% Energy Savings
Every motor operates on brushless DC stepless modulation, delivering significant energy reduction against fixed-speed benchmarks.
  • All rotating components use brushless DC technology
  • Real-time compressor thermal demand tracking
  • Adaptive outdoor fan speed control
  • Zone-by-zone airflow precision
  • Up to 40% energy reduction creates measurable operating cost savings
Duty Cycling Intelligent Compressor Management
Automatically rotates lead-lag assignment to ensure even wear distribution across the compressor bank.
  • Automatic rotation of lead-lag roles
  • Prevents premature compressor failure
  • Extends compressor bank life by 20-25%
  • Adds passive redundancy for critical applications
  • Configurable rotation intervals for field adaptation
Gold Fin Anti-Corrosion – 15-Year Coastal Durability
Hydrophilic coating provides salt spray resistance while improving condensate drainage in coastal environments.
  • Hydrophilic coating resists salt spray corrosion
  • Enhanced condensate drainage prevents water bridging
  • Maintains heat transfer performance for 15+ years
  • Validated across Gulf coastline and coastal deployments
  • Reduces ongoing coil cleaning maintenance requirements
HyperLink Communication – 1,000m Range with Native BMS Integration
Proprietary protocol supports distances up to 1,000 meters with native Modbus RTU and BACnet connectivity.
  • Supports up to 1,000 meters of refrigerant piping
  • Any network topology supported – star, tree, daisy-chain
  • Native Modbus RTU and BACnet integration
  • Automatic address configuration reduces commissioning time
  • Remote monitoring enables proactive service
Technical Specifications
SeriesV8 Pro
PositioningFlagship Full DC VRF – Contractor's Platform
Capacity Range8-134HP
Cooling Capacity5,300-86,000W
Airflow12,600-80,000 m3/h
Climate RatingT3 – 52°C full-capacity cooling, zero derating
IEER9.6
Drive TechnologyFull DC inverter – all motors brushless DC stepless
Energy SavingUp to 40% vs. conventional fixed-speed
RefrigerantR32 (GWP 675), F-Gas compliant
Max. Piping Length1,000m
Max. Height Difference90m
Compressor ManagementDuty Cycling intelligent load balancing
ProtectionGold Fin anti-corrosion + IP55 dust protection
Power SupplyDual frequency 50/60Hz, 180-440V, generator compatible
BMS ProtocolsModbus RTU, BACnet
Operation ModeHeat pump – cooling and heating
Indoor Units10 types compatible
Warranty5 years
OriginChina
Applications
  • Commercial towers requiring a single platform for multiple capacity tiers
  • Coastal hospitality projects needing corrosion resistance and extreme-heat performance
  • Government and institutional buildings in desert climates
  • Mixed-use developments with diverse zone requirements
  • Educational campuses requiring reliable cooling with minimal maintenance
  • Healthcare facilities where capacity consistency affects service reputation
Certifications & Standards
• CE • SASO • ESMA • GCC • Eurovent • TUV SUD • ISO 9001/14001/45001
