JIUCAN factory hot selling 41x41 41x21 Strut Channel Unistrut Slotted Strut Channel
JIUCAN factory hot selling 41x41 41x21 Strut Channel Unistrut Slotted Strut Channel
JIUCAN factory hot selling 41x41 41x21 Strut Channel Unistrut Slotted Strut Channel
JIUCAN factory hot selling 41x41 41x21 Strut Channel Unistrut Slotted Strut Channel
Specifications
Model Number :
JC-546
Processing Service :
Cutting, Punching, Drilling, Bending, Custom Fabrication
MOQ :
500 pcs
Delivery Time :
15-20 work days
Zinc Coating :
PG:40–275g/㎡ | HDG:40-85um/㎡
Payment Terms :
T/T,T/T
Exact Size :
41× 41mm/41x21mm Standard Unistrut Profile
Material :
Q235 / Q195 Carbon Steel
Brand Name :
Jiucan Metal
Key Features :
High load-bearing, anti-corrosion, anti-rust, seismic resistant, easy installation, no deformation, long service life
Packaging Details :
50 or 100PCS are packed in steel pallet , and fasten with steel strips
Price :
$1.5-$3/m
Wall Thickness :
1.5mm / 2.0mm / 2.5mm / 12GA / 14GA
Supply Ability :
50 to 80+ tons/day
Product name :
41x41/41x21mm Unistrut Channel
Packing :
Export pallet + waterproof film + woven bag
Certification :
ISO9001
Structure Type :
Solid / Slotted
Place of Origin :
Hebei,China
MOQ :
Negotiable, small trial order acceptable
Description

41x41mm 41x21mm Solid Unistrut Channel Seismic Bracing Strut Channel Manufacturer

Introduction

As a professional manufacturer, we provide 41x41mm/41x21mm and so on sizes Unistrut Channel for seismic bracing systems

Cold-formed one-piece Unistrut Channel, lightweight & high strength. The inner lip design enables fast assembly with spring nuts without on-site drilling for convenient installation.
Widely applied in photovoltaic and seismic support projects, manufactured from low carbon steel.
Pre-galvanized is recommended for indoor & dry areas, while hot-dip galvanizing is preferred for outdoor, rainy and humid environments.

Features

Solid back design provides excellent rigidity and seismic resistance. High-strength material ensures stable performance under dynamic loads. It effectively reduces displacement and damage during earthquakes. Compatible with seismic bracing accessories for fast installation. The channel features high durability, impact resistance, and long service life. It meets professional seismic standards and ensures safety for important infrastructure.



Specification



Item
Specification
Product Name
41x41 Unistrut Channel, 41x41 Strut Channel, 41x41 U Channel
Exact Size
41 × 41mm/41x21mm Standard Unistrut Profile
Thickness
1.5mm / 2.0mm / 2.5mm / 12GA / 14GA
Type Slotted/ Solid
Material
Q235B / Q195 Carbon Steel, SS304/SS316 Stainless Steel
Industry Standard
ASTM, EN, DIN International Standard
Surface Finish
Pre Galvanized, Hot Dip Galvanized HDG, Powder Coated
Zinc Coating
PG:40–275g/㎡ | HDG:40-85um/㎡
Standard Length
2.95m / 3m / 5.8m / 6m / 10ft / 20ft, Custom Cut Length
Processing Service
Cutting, Punching, Drilling, Bending, Custom Fabrication
Yield Strength
≥235MPa (Q235), ≥355MPa (Q355)
Tensile Strength
≥330MPa (Q235), ≥470MPa (Q355)
Key Features
High load-bearing, anti-corrosion, anti-rust, seismic resistant, easy installation, no deformation, long service life
Application
Pipe support, electrical conduit, cable tray, HVAC, solar mounting, seismic bracing, construction framing, mechanical support
Compatible Parts
Unistrut nuts, bolts, brackets, pipe clamps, seismic fittings, mounting accessories
Packing
Export pallet + waterproof film + woven bag
MOQ
Negotiable, small trial order acceptable
Delivery Time
15 working days
Payment
T/T, L/C, Western Union
Trade Terms
FOB, CIF, EXW



JIUCAN factory hot selling 41x41 41x21 Strut Channel Unistrut Slotted Strut Channel



FAQ

Q: Do you provide free sample?

A: Yes, but please note the transportation charge will be paid on your side.


Q: What kind of materail you can offer?
A: We can offer you GALVANIZED STEEL, STAINLESS STEEL, ALUMINUM, CABLE TRAY.

Q: What kind of standard you are following?
A: We are producing following by GB/T19001-2008, ISO9001:2008, SGS, MA...

Q: Could you change the size for the customer?
A: Yes, depends on your special demands.

Q: How many days delivery the order?
A: Normally 20 days after deposit or L/C, depends your request.
