Digital Readout System for Profile Projector with TTL Signal and High-Speed Counting, Stable Performance
Digital Readout System for Profile Projector with TTL Signal and High-Speed Counting, Stable Performance
Specifications
Brand Name :
UNIMETRO
Model Number :
UDC3000
Place of Origin :
China
MOQ :
1
Price :
Discussible
Payment Terms :
T/T
Supply Ability :
100 per month
Delivery Time :
5 work days
Packaging Details :
Paper box
Counting module :
Advanced 24 bits counting chip, CIE120703
Anti-noise capability :
Pulse group noise higher than 2kV, we have the experimental device in the factory
Production line control :
Function testing and aging testing, ensures the stability and reliability
Input voltage :
AC90V-240V
Input signal :
TTL, frequency <2MHZ, current>1mA
Weight :
1.8kg
Description
Digital Readout System for Profile Projector with TTL Signal and High-Speed Counting, Stable Performance
Product Overview

The DC-3000 digital readout system is a versatile digital display device designed for linear scales signal collection. Supporting TTL signal linear scales from various brands, it is widely used on profile projectors, tool microscopes, CCD measuring machines, and similar equipment.

Specifically designed for profile projector applications, this system offers comprehensive and powerful measuring functions including points, lines, circles basic elements measurement, user programming capabilities, coordinate system building, and point collection functions.

Key Features
  • Powerful anti-noise and signal anti-noise capability up to 2200V
  • No batteries required - system retains last position when powered on
  • Input power supply: AC 90V-240V
  • High-performance 24-bit counting IC with counting speed up to 4m/sec at 1μm resolution
Measurement Functions
  • Point, line, circle, angle, distance, rectangle, threads measurement and construction
  • Preset and construction capabilities with up to 50 point collection capacity
  • Coordinate straightening and offset functions to reduce adjustment time
  • Foot switch or optical edge detector support for fast point collection
  • Printing function for image elements or measurement result data
  • RS232 connection for linear scales counting output to PC
  • User programming function for recording and cycling measurement processes
  • Multiple coordinate types: rectangular axes and polar coordinates switchable
  • Unit display in inch and mm
  • Linear compensation and section compensation for linear scales
  • Z axis support for linear scales or encoders
  • 100 permanent image elements storage and 10 temporary storage spaces
Technical Parameters
Parameter Specification
Switch Power Supply Self-designed switch power supply using high-performance electronic components with NCC consumable components for stability and low maintenance
Counting Module Advanced 24-bit counting chip CIE120703 with integrated digital filter for stable counting and high anti-noise capability
Software Stable and powerful
Anti-noise Capability Pulse group noise higher than 2kV (factory-tested with experimental device)
Production Line Control Function testing and aging testing to ensure stability and reliability
Input Voltage AC 90V-240V
Power Consumption Lower than 15W
Input Signal TTL, frequency <2MHz, current >1mA
Resolution 0.1, 0.2, 0.5, 1, 2, 5, 10 μm available
Weight 1.8kg
Dimensions 296 × 184 × 68mm
Application
Digital Readout System for Profile Projector with TTL Signal and High-Speed Counting, Stable Performance
Company Information
Digital Readout System for Profile Projector with TTL Signal and High-Speed Counting, Stable Performance Digital Readout System for Profile Projector with TTL Signal and High-Speed Counting, Stable Performance Digital Readout System for Profile Projector with TTL Signal and High-Speed Counting, Stable Performance Digital Readout System for Profile Projector with TTL Signal and High-Speed Counting, Stable Performance
Our Clients & Agents
Digital Readout System for Profile Projector with TTL Signal and High-Speed Counting, Stable Performance Digital Readout System for Profile Projector with TTL Signal and High-Speed Counting, Stable Performance
Frequently Asked Questions
Q1: Are you a factory or trading company?
A1: We are a factory and provide responses within 24 hours.
Q2: What does your company mainly produce?
A2: We primarily manufacture Vision Measuring Machines, Coordinate Measuring Machines, CMM & VMM fixtures, and related equipment.
Q3: How to Choose the Appropriate Specification?
A3: Our professional team will recommend suitable measuring instrument specifications based on your product variety and size requirements.
Q4: Do you accept customized service?
A4: Yes, we provide both standard machines and customized solutions tailored to customer needs.
Q5: What is your warranty period?
A5: Our product warranty period is 1 year. We have enhanced product stability and improved breakable parts for reliable quality.
