Specifications
Brand Name :
Beijun
Model Number :
UQ-3
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
1000 Set/Sets per Month
Delivery Time :
7-15 days
Packaging Details :
Customized packaging
Engine Model :
CHANGCHAI 490
Engine Power :
63 HP
Transmission Model :
Ningjing 130
Drive Mode :
4x4
Dimension of Bottom Spring Plate :
Length 69mm, Width 11mm
Loading Capacity :
3 Tons
Type of Bucket :
U type Bucket
Thickness of Bucket Steel Plate :
bottom 6mm side 4mm
Description

Product parameters of 3 Ton Dump Truck

UQ-3 mining dump trucks mainly used for underground mines, above ground mines pit and mining areas, muddy roads, tunnel construction, Building construction, swamps, river beaches, deserts, paddy fields, tropical rain forests, snow and ice etc. The truck Certified to mine safety standards. It have the characteristics of large traction, good climbing performance and strong transportation capacity. The truck Dimension is small, Suitable for working in narrow mine tunnel. Exhaust gas treatment is Water filter purifier, reducing air pollution when working in underground mines.

Production operations using assembly lines. 1. Each job position is arranged in the order of product production process, and each position only completes one or a few fixed processes, with high level of craftsmanship and low error rate. 2. The production capacity of each position on the assembly line is balanced and proportional, so the company has strong production capacity and high product stability.

Beijun Heavy Industry is a large organization with high standards and strict requirements. It is a large-scale group company that integrates research and development, production, sales, after-sales service, and regards responsibility, integrity, pragmatism, innovation, and win-win as its corporate values. This is a group of young people with blood, resilience, vitality, and a spirit of hard work. The average age of employees is only 35 years old, which has overturned most people's understanding of the aging manufacturing industry. The company has a comprehensive organizational structure that can effectively and reasonably allocate various resources, effectively reduce business operating costs, improve productivity, and is an effective prerequisite for providing customers with high-end quality and reasonable prices

Model UQ-3
Engine Model CHANGCHAI 490
Engine Power 63 HP
Transmission Model Ningjing 130
Transmission Gear 4 Forward Gear, 1Back Gear,Rear High Speed Controller
Drive Mode 4x4
Front Axle Model CHITONG ISUZU Axle
Rear Axle Model CHITONG ISUZU Axle
Tire Model 700x16 Line Tire,
Rear Single Tyre One Side,
No.of Bottom Spring Plate Front 7 PCS, Rear 8 PCS, Spare 6PCS
Dimension of Bottom Spring Plate Length 70mm, Width 10mm
Size of the Bucket:Length×width×height 2400mm*1300mm*450mm
Type of Bucket U type Bucket
Thickness of Bucket Steel Plate bottom 6mm side 4mm
Unloading Type Hydraulic Double Top Dump
Steering Type Hydraulic power steering
Braking Type Air Brake
Cabin Canopy
Driving Position Left Hand Drive
Cooling sytem Standard Water Cooling System
Loading Capacity 3 Tons

3 Tons Underground Mining Truck Four Wheel Tunnel Articulated Diesel3 Tons Underground Mining Truck Four Wheel Tunnel Articulated Diesel3 Tons Underground Mining Truck Four Wheel Tunnel Articulated Diesel3 Tons Underground Mining Truck Four Wheel Tunnel Articulated Diesel3 Tons Underground Mining Truck Four Wheel Tunnel Articulated Diesel
